Product Features:
Product Name:High-definition underwater camera with recording function
Product Model:HX8000DVR/20
Baby UseWidely used in aquaculture (fish farming, raising sea cucumbers, etc.), underwater surveying, underwater operations (such as checking net box holes), scuba diving, underwater engineering acceptance, downhole observation (such as drilling and repairing wells), leisure and vacation, fishing, etc.;
Product Advantages:
7-inch high-definition color LCD display, low radiation and power consumption, long life, green and environmental protection;
High-definition low-light CCD lens, underwater no blind spots, with 2 LED high-brightness imported lights, stronger underwater penetration rate.
Portable hand-held waterproof case, powered by batteries, provides quick and convenient outdoor operations, allowing you to enjoy the underwater fun anytime and anywhere during leisure and vacation.With video recording function, includes a 2GB SD card.
Product Features:
★The truly fish-shaped shell design is both beautiful and elegant, making it highly attractive.
★600-line high-definition camera, the underwater and on-water effects are better.
★AV signal output/input, users can choose a standard monitor.
★Special cable lines with resistance to cold, water, corrosion, and tension, available in lengths of 20 meters, 30 meters, 50 meters, and 100 meters, with different prices depending on the length selected.
★Two 3W high-brightness white light bulbs with stronger light sources that can illuminate a longer distance.
★The structural design of the white light lamp and the camera being completely in different spaces makes the camera temperature low, and the lens inside is 100% free from water fog.
★Equipped with two weights, the lead weights serve a dual purpose of increasing the weight and protecting the fish-shaped shell.
★Equipped with a transparent fish tail, which serves to maintain balance and enable the camera to look downward.
Technical Specifications:
★16:9 High-Definition LCD Display
★Menu Display: English Screen Display
★Video format: PAL, NTSC format
★Charger: 100VAC-240VAC, DC 12.6V, 2000MA
★Battery: 4.5AH Sodium-Sulfur Battery. One charge can last for approximately 6 hours of continuous use.
★Battery life: About 8 hours
★Monitoring depth: 50 meters
★Lighting: 2 x 3W high-power bright white lights
★Camera angle: 120-degree wide-angle
★Camera Image: Color
★Underwater visibility: 1-3 meters (depending mainly on the water quality)
★Water pressure test: 5 atmospheric pressures
★Monitoring Image: Color
★Camera clarity: SONY 600 lines
★Monitoring input voltage: 12VDC
★Operating temperature: -20°C to 60°C
★Storage temperature: -30°C to 80°C
★Material of the sunshade: leather
★Minimum Illumination: 0Lux (with high-brightness white light on)
★Rated Current: 70mA (Maximum Current: 300mA when Infrared/White Light is On)
★Power Supply 12VDC
★Scanning System 2:1 Interlace
★Signal-to-Noise Ratio ≥ 48dB
★Auto White Balance On/Off
★Recording, Storage, Playback
★Storage: SD Card
Product Accessories:
One carry-on suitcase
1 set of 7-inch monitor (built-in in the rubber case)
Underwater Camera 50 meters 1 set (with cable and spool)
1 x 12V 4AH Battery
One battery cable
One battery charger
★ Delivery of 1 x 2GB memory card
Instruction Manual 1 (English) Optional Chinese
