led small beam light led glass ball spotlight led colorful beam light

GuangZhou MeiBo Stage Lighting Equipment Factory 12yr.

Contacts:

梁小姐Chat

Mobile:

86-13868967792

E-mail:

meibolight@qq.com

Click to Contact Yiwugo official customer service for International sourcing.

Yiwugo official customer service X

Whatsapp:

Email： yiwubuy@yiwugo.com

Description

Main Menu	Display content	Function
1	A001	DMX512(enterSwitch to channel mode selection).
2	RUNx	Run Mode SelectionX(soundFor voice control
3	color	Color manual dimming,enterSwitch to a different color mode
4	leon/loff	The digital tube is always lit or turned off, and the running status indicator light is used to display.
RUNX	<=8	No operation	RUN0	zeroing
	<32	pattern1	RUN1	4Color jump
	<64	pattern2	RUN2	Red base3Color jump
	<80	pattern3	RUN3	绿底3Color jump
	<96	pattern4	RUN4	Blue background3Color jump
	<112	pattern5	RUN5	White background3Color jump
	<128	pattern6	RUN6	All white with gradual transition
	<144	pattern7	RUN7	All white with a rapid gradient
	<160	pattern8	RUN8	Red to Green Gradient
	<176	pattern9	RUN9	Red to Blue Gradient
	<192	pattern10	RUN10	Blue to Green Gradient
	<208	pattern11	RUN11	Rainbow Gradient
	<224	pattern12	RUN12	Colorful Ribbon Change
	<250	Voice Control Mode2	SOU2	Voice control is not extinguished
	<256	Voice Control Mode3	SOU3	Voice-activated strobe
color	rxxx	0～255	Dimmer from dark to light
	gxxx	0～255	Dimmer from dark to light
	bxxx	0～255	Dimmer from dark to light
	yxxx	0～255	Dimmer from dark to light

nbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbspnbsp

DMXchannel	DMXNumerical	Detailed Features
1General Function Control	0 to 8	Turn off the light
	8 to 135	dial-up
	135~240	Flicker
	240~255	Switch
2RedLEDdial-up	0～255	Dimmer from dark to light
3GreenLEDdial-up	0～255	Dimmer from dark to light
4BlueLEDdial-up	0～255	Dimmer from dark to light
5WhiteLEDdial-up	0～255	Dimmer from dark to light
6self-propelled	<=8	No operation
	<32	pattern1
	<64	pattern2
	<80	pattern3
	<96	pattern4
	<112	pattern5
	<128	pattern6
	<144	pattern7
	<160	pattern8
	<176	pattern9
	<192	pattern10
	<208	pattern11
	<224	pattern12
	<240	Voice Control Mode1
	<250	Voice Control Mode2
	<256	Voice Control Mode3

Product Warranty Card

Under normal use of this product, any quality issues caused by the raw materials or the production process within one year from the date of purchase, our unit is responsible for free maintenance. Any damage caused by the user's installation, disassembly, or improper use in accordance with the product manual, our unit can provide maintenance, but will charge a reasonable service fee and parts cost.

Warranty Clause:

1. The product warranty period is one year.

2. Within one year from the date of purchase, under normal use (determined by our authorized technicians), free repairs or replacements will be provided for warranty parts that are damaged or malfunctioning.

3. Products that have been repaired or altered by maintenance personnel other than our maintenance center, or those that have been installed improperly, input incorrect voltage, used improperly, or suffered from faults due to accidental events or natural disasters are not covered by the warranty.

4. Before receiving warranty services, customers must present both the warranty card and the purchase proof to verify the purchase date of the electrical appliance. If the purchase date cannot be confirmed, the warranty will not be provided.

5. If the content of the warranty card is tampered with privately, it will be invalid.

Tip: Please provide your purchase proof when maintaining the machine. For convenience, please attach the purchase proof to the blank space below.

Product Name: _______________________________________

Model/Serial Number: ______________________________________

产地______________________________________

Purchase Date _______________________________________

Installation Date _______________________________________
