Price Negotiable
A new item has been added to your Shopping Cart. You now have items in your Shopping Cart.
GuangZhou MeiBo Stage Lighting Equipment Factory 12yr.
Contacts:梁小姐Chat
Mobile:86-13868967792
E-mail:
|
|
|
|
|
|
|
Address Code |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
YShaft Reverse |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
XShaft Reverse |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Manual color selection |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Demo Mode |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Voice Control Mode |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
System Reset |
Channel Table
|
12Channel Table |
||
|
channel |
"通道值"可以翻译为 "channel value"。 |
Function Description |
|
CH1 |
0-255 |
Total dimmer |
|
CH2 |
0 |
Red Close |
|
1-255 |
Gradually from dark to light |
|
|
methane |
0 |
Green Close |
|
1-255 |
Gradually from dark to light |
|
|
Methane |
0 |
Blue Close |
|
1-255 |
Gradually from dark to light |
|
|
CH6 |
0-255 |
Flicker increases from slow to fast |
|
CH7 |
0-255 |
Speed increases from slow to fast |
|
CH8 |
0-50 |
openCH1-CH6 |
|
51-100 |
Program Color Selection |
|
|
101-150 |
Program Gradual Change |
|
|
151-200 |
program pulse change |
|
|
201-250 |
Program Jump |
|
|
251-255 |
Voice Control On |
|
|
CH9 |
0-255 |
X |
|
CH10 |
0-255 |
Y |
|
CH11 |
0-255 |
XYSpeed |
|
CH12 |
255 |
Smoke spray increases from small to large |
Three: Master-Slave Setup
2or2The same lamps and lights as above3Core signal line connection, set any one host as the demonstration program or gradient, jump, other lamps set as the receiving addressA001。
Four: Technical Specifications
|
Voltage |
220V~240V 50-60Hz 100V~120V |
|
Model |
MB-F024A |
|
Power |
1500W |
|
Fuse |
230V/8A 110V/15A |
|
First Heat Time |
8minute |
|
Coverage |
10000 cubic feet per minute |
|
Oil capacity |
1.5liters |
|
LED |
36*3W RGB |
|
Weight |
25KG |
|
Volume |
51x47.5x56cm |
