| HVC-610S series | double-chamber vacuum packaging machine |
|
||||||||
|
||||||||
|
DZ-SA series Vacuum packaging machine only need to press the vacuum chamber cover to complete vacuum pumping and inflation according to the set procedure( optional), the whole process of sealing, printing, cooling and exhaust. After vacuum packaging, the articles can prevent oxidation, mildew, moth and moisture to prolong the storage period of the products. Note: letters in the model“Q” representative inflatable function. |
|
|
HVC-610S/2SA |
HVC-610S/2SB |
HVC-610S/2C |
HVC-610S/4C |
|
power supply voltage (V/Hz) |
AC 380/50 220/50 110/60 |
|||
|
Vacuum pump motor power (W) |
1100 |
|||
|
Heat sealing power (W) |
1000 |
800 × 2 |
||
|
Vacuum limit (Kpa) |
1 |
|||
|
Number of heat seals per Chamber |
2 |
4 |
||
|
Heat seal length (mm) |
610 |
|||
|
Heat seal width (mm) |
10 or 2 × 3 |
|||
|
Vacuum chamber size (L × W × H) (mm) |
720 × 550 × 160 |
720 × 550 × 150 |
720 × 550 × 45 |
720 × 630 × 45 |
|
Vacuum pump exhaust volume (m3/h) |
40 |
|||
|
Vacuum Chamber material |
Stainless steel Stainless steel |
|||
|
Overall dimension (L × W × H) (mm) |
1485 × 735 × 940 |
1485 × 735 × 930 |
1485 × 735 × 910 |
1485 × 820 × 910 |
|
Net Weight (kg) |
240 |
250 |
||
