Product Description:
BS-1510G the label shrink packaging machine adopts hot air circulation contraction, which is mainly aimed at the label contraction of products such as bottle shaped, can, barrel, CUP, etc., which can shrink the bottle body, bottom or mouth, suitable PVC, POF and other shrink packaging materials.
Technical characteristics:
1, all imported components, the heater is made of stainless steel.
2, the shrinkage temperature can be controlled at will, and the maximum temperature can reach250 ℃.
3, the conveying speed is steplessly regulated by the electronic governor.
4, only heating the bottle mouth part will not affect the quality of the objects in the bottle due to high temperature.
5, the whole machine adopts high-strength carbon steel, and the surface is treated with high quality.
6, double small power air transport motor, Turbine Air transport, will not cause label displacement and deformation.
7, you can adapt to various bottle types by simply setting and adjusting.
8, only for local heating of the product, the maximum energy saving.
9, this machine can be single-machine production or connected to production line operations.
Scope of Application:
BS-1510G label shrink packaging machine is suitable for containers such as glass bottles and plastic bottles in food, beverage, medicine, cosmetics, pesticide and other industries. The label of the bottle or cup body after trapping label is heat shrink.
Technical parameters:
|
|
BS-1510G
|
|
power supply voltage (V/Hz)
|
AC 220/50 110/60
|
|
Power (kw)
|
4.5
|
|
Packaging speed (pieces/hour)
|
8000-12000
|
|
Maximum packing size (φ×h)(mm)
|
* 120 × 400
|
|
Furnace cavity size (L × W × H)(mm)
|
1000 × 150 × 100
|
|
Applicable film
|
PVC, POF
|
|
Overall dimension (L × W × H)(mm)
|
1530 × 400 × 1300
|
|
Net Weight (kg)
|
180
|
|
