FBF series

paper bag cuffed packing automatic packaging machine

FBF-32A

Product Description:
FBC-2 this machine is suitable for packaging single (multi) layer paper bags and lined plastic bags. It can automatically complete heat sealing lined plastic bags, pressing inner bag, trimming bag mouth, folding line indentation, folding bag mouth, processes such as heating pressing and counting of hot melt adhesive paper tape and paper tape, and optional pocket dust collection device mechanism.

B- type heat sealing packaging is suitable for unpacking the bottom of the paper bag, then lifting the bag mouth, lining bag keep the sealed state and slide out by yourself. This packaging method is used to lining plastic bags with the same material as the inner materials. When adding materials, it only needs to be put together with bags, which is convenient to add raw materials and avoids the recycling of packaging bags.

Technical parameters:

	FBF-32A	FBF-42AD		FBF-32B		FBF-32BD
power supply voltage (V/Hz)	AC 380/50
Total power	6		6.5		6		6.5
Transmission power (KW)	0.75
Electric heater power (KW)	0.5 × 10
Sealing speed (m/min)	0-11
Temperature control range (℃)	0-400 adjustable
Dust Collector	×		√		×		√
Application	3-layer paper bag, lined with PE membrane bag heat seal, folding bag mouth and hot melt adhesive paper tape at a time
Hot melt adhesive paper tape specification (mm)	width 50mm, paper core 75mm
Overall dimension (L × W × H)(mm)	2790 × 950 × 1800	3050 × 950 × 1800		2790 × 950 × 1800		3050 × 950 × 1800
Net Weight (kg)	320	350		320		350

Process diagram:
