specifications

size

D x p

mm

The Width of the Width

Approx Weight

Kg/m unit length about weight

The Working Load Limit

T limit workload

The test load

KN test coincidence

The Breaking Load min.

KN computation

Inside the min.

A minimum inner width

Outside of Max.

B maximum external width

6 x18

7.5

21

0.79

1.1

27

45.2

7 x21

9

24.5

1.07

1.5

37

61.6

8 x24

10

28

1.38

2

48

80.4

10 x30

12.5

35

2.2

3.2

76

125

11 x43

12.6

36.5

2.33

3.8

92

154

12 x36

15

42

3.1

4.6

109

181

12.5 x38

15.5

42.2

3.3

4.9

117

196

13 x39

16.3

46

3.8

5

128

214

14 x42

18

49

4.13

6.3

150

250

14 x50

17

48

4

6.3

150

250

15 x46

20

52

5.17

7

168

280

16 x48

20

56

5.63

8

192

320

16 x49

24.5

59.5

5.71

8

192

320

16 x64

23.9

58.9

5.11

8

192

320

18 x54

23

63

6.85

10

246

410

18 x64

21

60

6.6

10

246

410

19 x57

23.7

63.2

7.7

11.3

270

450

20 the x60

25

70

8.6

12.5

300

500

22 x65

28

74.2

10.7

15.3

366

610

22 x66

28

77

10.2

15.3

366

610

22 x86

26

74

9.5

15.3

366

610

24 x72

32

82

12.78

18

432

720

24 x86

28

79

11.6

18

432

720

26 x78

35

91

14.87

21.3

510

850

26 x92

30

86

13.7

21.3

510

850

30 x90

38

105

19.6

28.3

678

1130

30 x108

34

98

18

28.3

678

1130

32 x96

40

106

22.29

32.2

772

1286
