1Safety Precautions
Please avoid installing locations containing flammable, explosive, corrosive gases, or dust.
② Please avoid installing the controller in direct sunlight or where it is exposed to rain.
Please do not insert any foreign objects into the case or spill any liquid into the case.
Please do not open or repair the controller on your own.
Avoid placing metal objects near the battery.
⑯ When the controller is operating, please do not touch the controller terminals and the baseboard to prevent electric shock or burns.
2Product Introduction
2.1 Product Overview
This series is a new generation of multi-functional and intelligent solar charging and discharging controllers. The innovative structured design makes the controller installation and use more safe and reliable, and the optimized charging and discharging management significantly improves the service life of the battery. At the same time, the largeLCDThe display screen contains a richer variety of display content, with beautiful and easy-to-understand patterns. The streamlined display management maximizes the visibility of the system's operational status and corresponding parameters. Multiple control parameters can be set to meet the diverse application requirements.
2.2 Functional Overview
IntelligentPWMCharging Mode
vividLCDGraphic Display
⑶ Concise button operation
⑷ Charge and discharge control parameters can be set
Automatic Temperature Compensation
⑯ Automatic recognition of battery voltage
⑺ Multiple Load Control Modes
USB Output Interface
Low Voltage Battery, Reverse Polarity, and Reverse Discharge Protection
3Installation Instructions
3.1 Installation Dimensions and System Wiring Diagram
3.2 Installation Steps
Please disconnect the battery and the fuse of the solar panel before installing the controller. Do not touch the positive and negative poles of the solar panel or the battery simultaneously during installation, or there is a risk of electric shock.
Controller up and down each leave15cmThe above space is beneficial for the controller to better dissipate heat. The current density of the system wiring cable is controlled.4A/mm²within" 或者 "within the range of
Step 1: Select an appropriate location and install the controller on a vertical surface.
Check the voltage of the battery and the solar cell components to ensure they are within the controller's required range.
Connect the battery first, then the controller.LCDDisplay is lit, as ifLCDPress if not lit5.2section processing
ⅴ Connect the solar cell components, and if there is a light controller, it will charge the battery.LCDThe charging indicator arrow lights up.
Connect the load.
4Instruction Manual
P1:Data Display Area P8:Voltage unit symbol
P2:Charging indicator P7: A-Amperes",缩写为 "AH-hour
P3:Solar panel P6:load
P4:Battery Power P5:Discharge Indicator
4.1.1 Button
|
Button |
Operation |
Functional Description |
|
|
short press |
In the main loop and the forward loop of the secondary sub-loop page, Increase the value in the parameter setting state |
|
Long press>3S |
Enter or exit the parameter setting page Enter the secondary loop page from the startup screen. |
|
|
|
short press |
Switch Load Reduce the value in the parameter setting state |
|
Long press>3S |
Exit the setting page for the secondary loop "at" working temperature”Page Restore to Factory Settings |
4.2 LCD Display Page Instructions
Power-on screen: After the system is powered on, the display will show the startup screen. If the system is correctly connected, the screen will display all the current related status and parameters.
⑵
In the "Boot Screen”Short press
Can be turned on or off.
⑶ Short press
"Positive feedback loop page. In the 'Increase Charging Voltage', 'Floating Charging Voltage', 'Low Voltage Protection Voltage', and 'Low Voltage Recovery Voltage' pages, long press '
"参"在中文中通常指的是"参"字,如果这是您想要翻译的,那么它的英文翻译是"cān"。Numerical values begin to blink, press short to proceed.
Or
The parameters can be increased or decreased.
"Work Temperature" page, by long pressing
Recover to factory settings. If the setting is successful, it will jump to the next page (i.e., the "Increase Charging Voltage" page).
4.2.2 LCD Secondary Cycle Page
In the main loop" power-on screen", by holding down the
Enter the secondary loop page. On the secondary loop page, press briefly
,可以正向循环页面 ,长按
Then enter the parameter setting, when the value flashes, press briefly.
Or
Adjust the parameter values to increase or decrease. After setting, long-press to confirm.
Save the settings and exit.
|
Usr:User-defined SLD:Sealed Battery Fibrous Line DefectOpen-Topped Lead-Acid Battery GEL:Colloidal battery LIo:Lithium battery |
-4 -4mV/Cell/°C |
15Hour: Normal Mode 14Hour: Light Control Mode 0-13Hour: Light-controlled and time-controlled mode |
5Faults and Maintenance
|
Fault Phenomenon |
Solution |
|
Battery under-voltage protection, load is shut down. |
Manually recharge the battery |
|
Overload or short circuit protection |
Reduce the load, eliminate short circuit faults, manually start the load. |
|
Battery overvoltage protection, load is shut down. |
Check the nominal voltage of the battery to see if it meets the system requirements. Check if the output voltage of other chargers connected to the battery is too high. |
6.Technical parameters
|
Rated Current |
5A |
10A |
15A |
20A |
self-consumption |
≤13mA |
|
|
System Voltage |
12V/24VAutomatic Recognition |
充SlashDischarge circuit voltage drop |
<0.2V/<0.1V |
||||
|
photovoltaicOpen-circuit voltage |
<50V |
USBOutput |
"最大"的英文翻译是 "maximum" 或 "largest"。5V/1A |
||||
|
Floating Charge Voltage |
13.8V/27.6V |
Wiring Specifications |
≤AWG12 |
||||
|
Low-voltage disconnect voltage |
10.7V/21.4V |
Working temperature |
-20°C~60°C |
||||
|
Low-voltage recovery voltage |
12.6V/25.2V |
Storage temperature |
-30°C~70°C |
||||
|
Increase the charging voltage |
Sealed14.4V/28.8V |
Charging Time |
Work humidity |
10%-90%No condensation |
|||
|
Colloid14.2V/28.4V |
Size |
168mm*88mm*28mm |
|||||
|
open one's mouth14.6V/29.2V |
2hour |
Installation hole diameter |
159mm*68mm- Φ4 |
||||
|
Overvoltage Disconnection Voltage |
15.5V/31.0V |
Net weight |
220g |
||||
|
Overvoltage Recovery Voltage |
15.0V/30.0V |
|
|
||||
