Datalogic Qd2430 Scanning Gun (Two-Dimensional, Including Bracket)

Datalogic Qd2430 Scanning Gun (Two-Dimensional, Including Bracket) 中文版

1 piece

Please select a product

	Number		Unit-price		Total
I want to buy：		×	720.0	=	0

The purchase quantity of each ID cannot exceed()piece

Insufficient inventory, please contact the seller

The total number of orders is less than the minimum purchase quantity(1)

A new item has been added to your Shopping Cart. You now have items in your Shopping Cart.

Continue Shopping View Shopping Cart

Contacts:

Wang HaoyangChat

Mobile:

86-13551138549

E-mail:

278793410@qq.com

Click to Contact Yiwugo official customer service for International sourcing.

Yiwugo official customer service X

Whatsapp:

Performance Parameters
Device Type	Barcode Scanner
Scanning method	"影像式"可以翻译为 "image-based".
Resolution	Maximum: 0.102mm/4 mils (Linear Codes)
light source	Illumination: Red LED with a wavelength of 610-650nm, Aiming: 2 blue LEDs
Depth of field	The minimum depth of field is determined by the barcode length and scanning angle; it varies with print resolution, contrast, and ambient light.
Scan Angle	Curl: +/-360°, Tilt: +/-65°, Warp (Deviation): +/-60°
interface	Composite keyboard port/OEM (IBM) USB port/RS-232 serial port/USB port
Decoding ability	1D barcode/Linear barcode: Can automatically distinguish and decode all standard 1D barcodes including GS1 DataBar linear barcodes. 二维码：Aztec Code, Aztec Mesas, Data Matrix, MaxiCode, Micro QR Code, QR Code, 中国汉信码 Stack bar codes: EAN/JAN Composites, GS1 DataBar Composites, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, MacroPDF, MicroPDF417, PDF417, UPC A/E Composites Postal Code: KIX Post, Planet Code, Postnet, Royal Mail Code (RM4SCC), China Post Code, Canadian Postal Code, Japan Postal Code, Australian Postal Code, UK Postal Code, Korean Post Office Code
Print Contrast	25%

Mechanical/Electrical Performance
prompt method	Successfully read the indicator: Beeper (tuneable tone), DATALOGIC 'Green Dot' successfully read feedback, read aiming LED
Power supply	Working Condition (Nominal): 140mA @ 5V DC Standby/Idle (Nominal): 50mA @ 5V DC Input Voltage: 4.5-14V DC +/-10%

Other parameters
Product Size	163×91×41mm
Product Weight	0.145kg
environmental parameters	Working condition: 0-50℃/32-122°F, humidity: 0-95% non-condensing Storage/Transport: -40-70°C/-40-158°F Ambient Light: 86000 lux ESD Electrostatic Discharge Protection (Air Discharge: 16kV) Impact resistance: able to withstand multiple drops from 1.5 meters/5 feet onto concrete floors.
Other functions	Waterproof and dustproof seal level: IP42 Image Sensor: Wide VGA: 752×480 pixels Mobile Tolerance: 25 IPS Code 39: 5 mils: 0.5-15cm/0.2-5.9 in Data Matrix: 10 mils: 1-13cm/0.4-5.1 in EAN/UPCA: 13 mils: 0.5-35cm/0.2-13.8 in PDF417: 6.6 mils: 1-13cm/0.4-5.1 in

Update time：20221121180625
