Basic characteristics
ProductName:ReceiptPrinter
ItemNumber: POS-8250
It can be used for all kinds of commercial applications in retail POS systems, restaurant systems, and industrial control systems in areas such as...
Question mark Lightweight and portable
Question mark Beautiful shape
Question mark Low-cost and High-quality Thermal Printing
Question mark Cashdrawerdrivesupported
Question mark Easy paper roll installation, easy maintenance, and rational structure
Question mark Low-power waste, low-run cost (without the ribbons, ink cartridges)
Question mark Built-in data buffers (capable of receiving print data while printing)
Question mark Character can be amplified. printed in bold optionally, and linespacing printing
can be adjusted
Question mark Support different density bitmap graphics printing
Question mark Support for NVIDIA image downloading and printing
Question mark Support for raster bitmap printing
Question mark High-speed printing using embedded soft font for all interfaces.
Question mark Compatible with ESC/POS print instruction set, optional columns and
font(adjusted by DIP switch
Advantage Characteristics
-Audible and visual alarm external device available (Best application for kitchen menu printing)
-Front-Feeding structure (Water & Oil resistant design)
-USB port, Serial port, and Ethernet interface
ParameterDetail
Printing Method: Thermal Inkjet Printing
Charactersize:512 dots/line
Font A: 12 dots * 24 dots, 1.5 (W) * 3.0 (H) mm
Font B: 9 * 17 dots, 1.1 (W) * 2.1 (H) mm
Simplified/Traditional:24*24 dots, 3.0(W)*3.0(H)mm
Print parameters: Support to download the Logotrademark
Printing Chinese character: Chinese: Simplified Chinese 24x24 point. Support 18030 font library, support Taiwan and HK traditional (complex font)
ANK:ANK characters
Extended character table:
OEM437/Katakana/OEM850/OEM860/OEM863/OEM865/WestEurope/Greek/Hebrew/East Europe/Iran/WPC1252/OEM866/OEM852/OEM858
IranII/Latvian/Arabic/PT1511251/OEM747/WPC1257/Vietnam/OEM864/Hebrew/WPC1255/Thai
BarcodeTypes:UPC-A/UPC-E/JAN13(EAN13）/JAN8(EAN8）CODABAR/ITF/CODE39/CODE93/CODE128
PrintSpeed:300mm/second
Interface: Parallel/Serial port/USB port/Ethernet
Emulation: ESC/POS command
Print width: 79.5±0.5mm (print width 72mm)
PrintDiameter:83mm
Print thickness: 0.06-0.08mm
Power:DC24V/2.5A
Cutter: Full or Partial Cut
Reliability print: 100 km
Weight: 2.2kg
Temperature: 0-45°C"℃" is the symbol for Celsius temperature scale.
Contrast Humidity: 10-80percent
|
名 称： Bill Printer
Type Number: POS-8250
Adaptable to various commercial applicationsRetailPOSSystem, Food Service System, Industrial Control SystemWaitfield
Compact and lightweight, with a beautiful design
Print quality is high and the cost is low.
Low noise, high speed printing
Support for the money box drive
Easy-to-assemble paper structure, rational design, easy to use and maintain.
Low power consumption and low operating cost (no need for toner or ink cartridges)
Built-in data buffer (capable of receiving print data when printing)
Characters can be enlarged and printed, and the character line spacing can be adjusted for printing.
Support different density bitmaps and download graphics for printing.
Support for raster bitmap printing
To achieve high-speed printing comparable to the call to the hard-coded library under the driver printing method.
CompatibleESC/POSPrinting Instruction Set, Adjustable in Multiple Modes"DIP" 可以翻译成 "Direct Injection Plasma" 或 "Direct Injection Plasma"。On/Off
Advantageous characteristics
- Supports single-sound and light indication function, using an external sound and light alarm indicator. The alarm is compact and elegant, and is not factory-equipped. Customers can choose to add it. The standard length of the external cable is 2 meters (customizable based on actual needs). It is more practical for kitchen menu printing.
-Adopting a structural design (waterproof and oil-proof), the product has enhanced practicality in kitchen environments.
- The high degree of integration of the interface, with U, serial, and Ethernet ports available. Interface 1: USB Interface 2: USB + Ethernet Interface 3: USB + Ethernet + Serial
Technical parameters
Print Mode: Direct-Line Thermal
Character size: 512 dots per line
Font A: 12 * 24 points, 1.5 (width) * 3.0 (height) mm
FontB: 9 * 17 points, 1.1 (width) * 2.1 (height) mm
Simplified/Traditional Chinese: 24*24 dots, 3.0(width) * 3.0(height) mm
Language: Supports multiple languages
Printing parameters: Supports downloading and printing the company logo.
Character Chinese: Supports the national standard I. Second-level Chinese character library, supports the 18030 large character library, and supports the Taiwan, Hong Kong traditional Chinese character library.
"Western: ANK character
Extended Character Set: OEM437/Katakana/OEM850/OEM860/OEM863/OEM865
West Europe/Greek/Hebrew/East Europe/Iran/WPC1252/OEM866/OEM852/OEM858/Iran II
Latvian/Arabic/PT151,1251/OEM747/WPC1257/Vietnam/OEM864/Hebrew/WPC1255/Thai
Barcode types: UPC-A/UPC-E/JAN13 (EAN13)/JAN8 (EAN8) CODABAR/ITF/CODE39/CODE93/CODE128
Print speed: 300 mm/second
Interface Type: Parallel/Serial/USB/Ethernet
Print command: Compatible with ESC/POS commands
Print paper width: 79.5±0.5 mm (print width: 72 mm)
Print paper outer diameter: 80mm
Print paper thickness: 0.06-0.08 mm
Power Supply: DC24V/2.5A
Automatic knife: full cut or half cut
Reliability: 100 kilometers
Weight: 2.2 kilograms
Temperature: 0-45°C
Relative Humidity: 10-80%
Driver: Win2000, Win2003, WinXP, WinVista, Win7, Win8, Linux
Compatible with Epson, Samsung
Dimensions (L*W*H): 190*145*145 (mm)
|
Drivers: Win9X/Win2000/Win2003/WinVista/Win7/WindowXP/win8/linux
Compatible with Epson, Samsung
External Dimension (L*W*H): 190*145*145mm

|
