New Quick Copy Remote Control Product Specification

描述全新快速复制遥控器

I. OverviewOverview

In the process of configuring sales, many customers hope to have a universal remote control to replace the original remote control, but such a remote control has not been released until now. Our“Copy-type remote control”As long as you meet the following three conditions,just in2Configure your remote control in seconds with ease.

In the configuration and selling process, most clients wish to replace the original remote control with a general remote control, while such remote control has not been developed. You may configure your remote control within 2 seconds if you meet the following three conditions:

Condition One,The original remote control was functioning normally.

Condition I: the original remote control may be used normally

Condition Two,Clear the original remote control's transmitting frequency(Disassemble the original remote control and refer to the diagram below")

Condition II: know the transmission frequency of the original remote control (referring to the following diagram)

Condition Three.Original Remote Control EncodingIC为PT2262, PT2264, SC2262, SC2260, HS2262, 2260, LX2262, 2260, EV1527, PT2240And some non-standard remote controls.

Condition III: The IC of the original remote control is PT2262, PT2264, SC2262, SC2260, HS2262, 2260, LX2262, 2260, EV1527, PT2240, or without code.

Section Two: Methods of DuplicationCopying method

1andPerform a zeroing operation before the clone同时按下对拷型遥控器上排两个按键（一定要同时按下才有效），见到LEDTurn on the light, then turn it off, don't let go untilLEDThe flashing light indicates that the reset has been successful. After the reset is successful, press the remote control button,LEDThe light is on and then off.

Resetting before copying: press two keys on the copying remote control at the same time until the LED flashes, indicating the resetting is successful. After resetting, press the key of the remote control, and the LED will be off.

2andduplicate对拷前请注意产品的正确放置，应该将原遥控器与对拷型遥控器并排靠在一起放置在桌面。用右手按下对拷型遥控器下箭头按键不松手，见到LEDThe light turns on and then off, indicating that the copy mode has been entered. Quickly press the corresponding button on the original remote control with your left hand, and see the copy remote control.LEDThe flashlight is successful if the key is successfully copied, and the method of copying multiple keys is the same.

Before copying, please place the product correctly. Place the original remote control and the copying remote control on the desk. Use your right hand to press the copying remote control until the LED is on or off, indicating that it has entered the copying status. Use your left hand to press the key of the original remote control. The fast clicking of the LED of the remote control indicates success in copying.The copying method is the same as for several keys

3anduse a small doorIf you accidentally reset the code of the dual-copy remote control, you can restore it by holding down both buttons at the same time without letting go.LEDAfter the light turns on and then turns off, don't let go untilLEDThe flashing light indicates that the recovery has been successful.

Tips: If you reset the code of the remote control and want to recover, press two keys until the LED light flicks.

Section Three: Technical SpecificationsTechnical parameters

1This product can be copied from the original remote control.ICModel number2262 2260 1527 2240and compatibleICAnd so on.

The original remote control IC model is 2262 2260 1527 2240 and compatible IC

2Do not consider the oscillation resistance and address encoding, this product will automatically be compatible with the oscillation resistance and address encoding.

考虑抗振性和地址编码是多余的。该项目可能与抗振性和地址编码兼容。

3This product is not copyable.ICsuch asHCS300 301and compatible rolling codeICAnd so on.

The inapplicable IC is HCS300 30 and compatible rolling code IC

4The battery used in this product is12V 23AIf the remote control distance is insufficient, please replace the batteries.

The battery used in the product is 12V and 23 A. Please replace the battery when the remote control distance is insufficient.

5This remote control operates on a fixed working frequency, commonly used for...315MHz"";433MHzCustomizable for other frequencies.

The fixed working frequency is 315MHz"";433MHz; other frequencies may be customized.
