Product Features

High precision:
repeated positioning accuracy can reach 0.06mm
variety:
u-type, L-type, O-type, H-type, first adjustable, etc.
Good quality:
the materials used have high strength and precision.
Good fit:
supports robots of most brands such as ABB and KUKA.

Product Parameters

Rated load: ≤ 1000kg
radius of gyration: R600mm
primary shaft flip angle: ± 180 °
output shaft rotation angle: ± 360 °
primary shaft rated speed: 20 °/s
output shaft rated speed: 30 °/5
repeated precise positioning: ± 0.15mm
dimension (mm):4200X700X1800
height of one-axis rotation center: 1500mm
two-axis rotary disk: Platinum 1500mm
power supply conditions: Three-phase 220V ± 10%,50Hz
insulation grade: H
net weight of equipment: about 2200kg

dr. Gong's brand dislodgement machine has excellent technical strength, strict quality control, rich product categories and good cost performance advantages.
