New Quick Copy Remote Control Product Specification

描述全新快速复制遥控器

1. Overview

During the process of configuring sales, many customers hope to have a universal remote control to replace the original remote control, but such a remote control has not been released until now. Our "Copy-type Remote Control" can be easily configured in 2 seconds as long as you meet the following three conditions.

In the configuration and selling process, most clients wish to replace the original remote control with a general remote control, while such remote control has not been developed. You may configure your remote control within 2 seconds if you meet the following three conditions:

Condition 1: The original remote control is functioning normally.

Condition I: the original remote control may be used normally

Condition 2: Understand the original remote control's transmitting frequency (Refer to the diagram below after opening the original remote control)

Condition II: know the transmission frequency of the original remote control (referring to the following diagram)

Condition 3: The original remote control encoding IC is PT2262, PT2264, SC2262, SC2260, HS2262, 2260, LX2262, 2260, EV1527, PT2240, and some non-standard code remote controls.

Condition III: The IC of the original remote control is PT2262, PT2264, SC2262, SC2260, HS2262, 2260, LX2262, 2260, EV1527, PT2240, or without code.

2. The method of copying

1. Perform the zeroing operation before the cloning: Press the two buttons on the top row of the cloning remote control simultaneously (it must be pressed simultaneously for it to work), and when you see the LED light flash and then turn off, do not release your hand until the LED light flashes, which indicates that the zeroing has been successful. After the success of the zeroing, press the remote control button, and the LED light will turn on and then turn off.

Resetting before copying: press two keys on the copying remote control at the same time until the LED flashes, indicating the resetting is successful. After resetting, press the key of the remote control, and the LED will be off.

2. Pairing: Before pairing, please ensure the correct placement of the product. The original remote control should be placed side by side with the pairing remote control on the table. Press the down arrow button on the pairing remote control with your right hand without releasing, and when the LED light is lit and then extinguished, it indicates that the copying state has entered. With your left hand, quickly press the corresponding button on the original remote control. If the LED light on the pairing remote control flashes quickly, the pairing is successful. The method for pairing multiple keys is the same.

Before copying, please place the product correctly. Place the original remote control and the copying remote control on the desk. Use your right hand to press the copying remote control until the LED is on or off, indicating that it has entered the copying status. Use your left hand to press the key of the original remote control. The fast clicking of the LED of the remote control indicates success in copying.The copying method is the same as for several keys

3. Use a trick: If you accidentally reset the code of the copy-type remote control, you can restore it by holding down both buttons at the same time without letting go. When the LED light blinks once and then turns off, keep holding until the LED light flashes continuously, which indicates that the restoration has succeeded.

Tips: If you reset the code of the remote control and want to recover, press two keys until the LED light flicks.

III. Technical parameters

1. The original remote control IC models that this product can copy are 2262, 2260, 1527, 2240, and compatible ICs, etc.

The original remote control IC model is 2262 2260 1527 2240 and compatible IC

2. No need to consider the oscillation resistance and address encoding, this product will automatically be compatible with the oscillation resistance and address encoding.

考虑抗振性和地址编码是多余的。该项目可能与抗振性和地址编码兼容。

3. This product includes non-copyable ICs such as HCS300, 301, and compatible rolling code ICs.

The inapplicable IC is HCS300 30 and compatible rolling code IC

4. The battery used in this product is 12V 23A. Please replace the battery when the remote control distance is insufficient.

The battery used in the product is 12V and 23 A. Please replace the battery when the remote control distance is insufficient.

5. This remote control operates at a fixed working frequency, commonly 315MHz or 433MHz. It can also be customized for other frequencies.

The fixed working frequency is 315MHz; 433MHz; other frequencies may be customized.
