Product Features
1. Oil-immersed gear, durable aluminum alloy shell.
2. Optional built-in control board or external control unit with integrated receiver.
3. Keyboard/Single-Button Interface.
4. Alarm light, beam and safety beam interface.
5. Self-locking structure, mechanical limit switch.
6. The standard output shaft hole diameter is 25.40 mm, and it can be adjusted to a hole diameter of 40.00 mm using a metal adapter.
7. Emergency release system for manual chain operation.

Product Parameters:

Model: GY40-150
Power supply: AC220V/50Hz; AC380V-400V
Motor power: 300-750W
Output Torque: 40-150N.m
Floor area: 20-45 Sq.m.
Motor size: 236×110×375mm
Limit switch: Mechanical limit switch
Output shaft hole diameter: 25.40 mm
Remote control ratio: 58: 1
Remote control range: ≥30m
Remote control record times: 25
Frequency: 433.92MHz
Working hours: S2 15min
Working temperature: -20°C to 70°C
Packing Weight: Motor 14KG, Control Unit 3KG
