Schneider MCB A9R71225 protector electrical circuit breaker

Main information
Product series Acti 9
Product name Acti9 iID
Product Type Residual Current Circuit Breaker (rccb
Product short name iID
Pole number 2P
Left of neutral line position
Rated current [In] 25 A
Power grid type AC
Residual current sensitivity 30 mA
Selective instantaneous type of residual current action protection
Leakage current protection level Type A-SI (Super Immunised)
additional information
Distribution system location downstream distribution outlet line
Power grid frequency 50/60 Hz
Rated working voltage [Ue] 220...240 V AC 50/60 Hz.
Residual current action technology action function has nothing to do with power supply voltage.
Rated breaking and connecting energy Idm 1500 A
Im 1500 A
Rated short-circuit current 10 kA
Rated isolation voltage [Ui] 500 V AC 50/60 Hz.
Rated impulse withstand voltage [Uimp] 6 kV
Surge current 3000 A
Contact position indications are as follows
Control type handle
Installation type locking clip locking
Installation mode DIN guide rail installation
Width (multiple of 9mm) 4
Height 91 mm
Width 36 mm
Depth 73.5 mm
Net weight 0.21 kg
