EDS-208A series 8-port industrial Ethernet switches are equipped with IEEE 802.3 and IEEE 802.3u/x, 10/100M full/half-duplex, MDI/MDI-X adaptive. EDS-208A series 12/24/48 VDC(9.6 to 60 VDC) redundant dual power input, which can connect two live DC power supplies at the same time. This series of switches are specially designed for harsh industrial environments, such as maritime (DNV/GL/LR/ABS/NK), rail transit, expressway or mobile applications (EN 50121-4/NEMA TS2/e-Mark), and meet FCC, UL and CE standards.

The EDS-208A switch supports -10 to 60°C standard temperature or -40 to 75°C wide temperature operation. All models have passed the 100% burn-in test to meet the special needs of industrial automation control applications. In addition, EDS-208A switch has DIP switch, which can enable or disable broadcast storm protection, providing flexible solutions for different industrial applications.
specifications
Ethernet interface
10/100BaseT(X) port (RJ45 connector) eds-208a/208a-t: 8
EDS-208A-M-SC/M-ST/S-SC series: 7
EDS-208A-MM-SC/MM-ST/SS-SC series: 6
All models support:
Rate adaptation
Full/Half-duplex mode
Automatic MDI/MDI-X connection
100BaseFX port (multimode SC connector) EDS-208A-M-SC series: 1
EDS-208A-MM-SC series: 2
100BaseFX port (multimode ST connector) EDS-208A-M-ST series: 1
EDS-208A-MM-ST series: 2
100BaseFX port (single mode SC connector) EDS-208A-S-SC series: 1
EDS-208A-SS-SC series: 2
Standard IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseT(X) and 100BaseFX.
IEEE 802.3x for flow control.

Exchange characteristic
MAC address table size 2 K
Packet buffer size is 768 kb.
Processing type store and forward
Power supply parameters
Connect a detachable 4-contact terminal.
Input current EDS-208A/208A-T, EDS-208A-M-SC/M-ST/S-SC series: 0.11 A @ 24 VDC.
Series EDS-208A-MM-SC/MM-ST/SS-SC: 0.15 A @ 24 VDC.
Input voltage 12/24/48 VDC, redundant dual power input.
Operating voltage is 9.6 to 60 VDC.
Overload current protection support
Reverse connection protection support
DIP switch configuration
Ethernet interface broadcast storm protection
mechanical properties
Shell aluminum
IP grade IP30
Dimensions 50 x 114 x 70 mm(1.96 x 4.49 x 2.76 inches)
Weight 275 g (0.61 lb)
Installation rail installation, wall-mounted installation (with optional kit)
