Product Usage
1. Isolate DC: The function is to prevent direct current from passing while allowing alternating current to pass.
Bypass (decoupling): Provides a low-impedance path for certain parallel components in AC circuits.
Coupling: As a connection between two circuits, allowing AC signals to pass through and transmit to the next level of the circuit.
4. Filtering: This is very important for DIY, as most capacitors on the graphics card serve this purpose.
5. Temperature Compensation: To compensate for the impact of insufficient temperature adaptation of other components, and to improve the stability of the circuit.
6. Timing: Capacitors and resistors are used together to determine the circuit's time constant.
7. Tuning: Systematic tuning of circuits related to frequency, such as mobile phones, radios, and televisions.
8. Rectification: Opening or closing the semi-conductor switch element at a predetermined time.
9. Energy Storage: Storing electrical energy for later release when needed. Examples include flashlights for cameras and heating devices.
