The VFD-C2000 series: This series features high-efficiency variable-frequency drive technology with FOC control at its core. It offers a diverse range of drive control and modular design, rich industrial application functions, and self-diagnostic features that are easy to maintain with low failure rates. It has competitive market capabilities and effectively saves construction and operational costs for industrial and end customers. It helps users seize the initiative and enhance their competitiveness!

Technical Specification:

The output frequency is generally 0.01-600Hz for light load and 0.00-300Hz for heavy load.

Integration of Induction Motor and Synchronous Motor Control

Speed/Torque/Position Control Mode

Built-in 10k capacity PLC

Standard configuration with LCD panel, optional with LED.

Overload Capacity: General Load Rated Output Current 120% for 1 Minute; Heavy Load Rated Output Current 150% for 1 Minute

Built-in DC reactors (37kW), brake braking unit (30kW)

Embedded with CANopen fieldbus and Modbus, and can be selected with: DeviceNet, Profibus, ModbusTCP, and EtherNet-IP.

Built-in temperature sensor

DC-BUS can be parallel shared

Through-the-wall installation method, which enhances the protection level of the system.

Detachable fan, control terminals

Enhanced environmental tolerance and protection

Application field:

Large fans, pumps, winding equipment, air compressors, machine tool equipment, precision processing centers, food packaging, medical equipment, dyeing and printing equipment, elevator hoisting industry, etc.
