Product Introduction
Floor-embedded forced-air convection radiator
Floor-embedded forced convection type radiators are based on natural convection and add silent cross-flow fans to enable limited heat dissipation elements to output large amounts of heat. They feature strong power, instant use, rapid heating, and effective energy saving.
Takeover method
The heat exchanger shell is 300mm longer than the heat transfer elements. It can be perforated at the end, side, or on-site for installation to connect with the heating main pipe. The interface pipe diameter can be DN15 or DN20.
Floor-embedded (drainage) forced-air convection radiator specifications cm
Length: 1250/1750/2250/2750/3250
Width: 200/280/340/400
Height: 115
Fan speed grade, sound pressure level, airflow, operating heat dissipation, for specific details, please contact customer service at 18538120969.Floor-Embedded Series
Product performance advantages

A. Energy-saving pioneer, low capacity, high heat dissipation efficiency
The special internal structure of the copper tube convection radiator has less water capacity, allowing it to heat up quickly in a single unit of time. Additionally, using copper pipes as the waterway and aluminum fins as the heat dissipation wings, copper and aluminum have superior thermal conductivity compared to other materials. Therefore, the copper tube convection radiator achieves the highest heat dissipation efficiency in a single unit of time.

B. Low surface temperature, non-injurious
Copper tube convection radiators employ the principle of convection heat dissipation, so the temperature of their shells remains constant at around 40 degrees, which is quite similar to human body temperature, making them a safe and protective measure for the elderly and children. The convection effect generated by the radiators can maintain an effective temperature balance in every part of the room, creating a small microclimate with excellent comfort.

C. Easy to maintain and clean
Copper pipes have excellent corrosion resistance, so they do not need to be filled with water for maintenance. The air valve is built in, and after installation, it can be used directly after releasing the air once. The smooth surface of the shell can be removed, which is very convenient for cleaning for families with high hygiene requirements.

D. The main body of the copper pipe is corrosion-resistant, pressure-resistant, and safe to use. Under the same water quality erosion conditions, the corrosion resistance of copper pipes is 21 times that of steel pipes. The incidence of corrosion perforation accidents in copper pipes is low. In addition, the copper pipe is extruded into shape, and the destructive test pressure of the 0.6mm thin-walled copper pipe can reach 100 kilograms.
For specific details, you can contact the customer service at 18538120969 within 24 hours.
