| 3kw | ¥4055.0 | 50000 set available |
|
| 4kw | ¥4530.0 | 50000 set available |
|
| 5kw | ¥5004.0 | 50000 set available |
|
| 6kw | ¥5384.0 | 50000 set available |
|
| 8kw | ¥5953.0 | 50000 set available |
|
A new item has been added to your Shopping Cart. You now have items in your Shopping Cart.
Yang BoChat
Mobile:86-13732441469
E-mail:
|
Product Model
|
HYX-H3K-HS
|
HYX-H3K6-HS
|
HYX-H4K-HS
|
HYX-H5K-HS
|
HYX-H4K6-HS
|
HYX-H6K-HS
|
HYX-H8K-HS
|
|
DC input
|
|||||||
|
The maximum configurable power
|
6,000W
|
7,200W
|
8,000W
|
9,200W
|
10,000W
|
12,000W
|
1,6000W
|
|
Maximum input power
|
3,000W / 1,800W
|
3,600W / 2,160W
|
4,000W / 2,400W
|
4,600W / 2,760W
|
5,000W / 3,000W
|
5,000W / 4,600W
|
6,400W / 6,400W
|
|
Maximum input voltage
|
600V
|
||||||
|
Starting voltage
|
50V
|
||||||
|
MPPT operating voltage range
|
80 - 560V
|
||||||
|
Maximum input current
|
32A (16 / 16)
|
||||||
|
Maximum short-circuit current
|
48A (24 / 24)
|
||||||
|
MPPT lanes
|
2
|
||||||
|
Number of PV inputs (number of MPPT strings per channel)
|
2 (1 / 1)
|
||||||
|
AC input/output
|
|||||||
|
Nominal power
|
3000W
|
3600W
|
4000W
|
4600W
|
5000W
|
6000W
|
8000W
|
|
Maximum apparent power
|
3300VA
|
4000VA
|
4400VA
|
5060VA
|
5500VA
|
6600VA
|
8800VA
|
|
Nominal current
|
13.6A
|
16.3A
|
18.1A
|
20.9A
|
22.7A
|
27.2A
|
36.3A
|
|
Maximum current
|
15.0A
|
18.0A
|
20.0A
|
23.0A
|
25.0A
|
30.0A
|
40.0A
|
|
Nominal Voltage
|
1 / N / PE, 220V / 230V / 240V
|
||||||
|
AC Voltage Range
|
154 ~ 276V
|
||||||
|
Total harmonic distortion
|
< 3%
|
||||||
|
Frequency
|
50Hz / 45~55Hz; 60Hz / 55~65Hz
|
||||||
|
Adjustable power factor
|
0.8 Lead ... 0.8 lag
|
||||||
|
DC current injection
|
< 0.5% In
|
||||||
|
Off-grid output
|
|||||||
|
Nominal Output Power
|
3000W
|
3600W
|
4000W
|
4600W
|
5000W
|
6000W
|
6000W
|
|
Maximum Continuous Output Apparent Power
|
3300VA
|
4000VA
|
4000VA
|
5060VA
|
5060VA
|
5060VA
|
8000VA
|
|
Peak Output Power
|
4,500W; 10s
|
5,400W; 10s
|
6,000W; 10s
|
6,900W; 10s
|
7,500W; 10s
|
9,000W; 10s
|
12,000W; 10s
|
|
Maximum Output Current
|
15.0A
|
18.0A
|
20.0A
|
23.0A
|
25.0A
|
30.0A
|
36.3A
|
|
cutoff time
|
< 10ms
|
||||||
|
Battery Input
|
|||||||
|
Battery Type
|
LiFePO4
|
||||||
|
Battery Voltage Range
|
80 ~ 490V
|
||||||
|
Maximum charge/discharge current
|
35A
|
||||||
|
Maximum Charge/Discharge Power
|
8,000W
|
||||||
|
Efficiency
|
|||||||
|
Maximum efficiency
|
98.60%
|
||||||
|
European Weighted Efficiency
|
98.20%
|
||||||
|
MPPT Efficiency
|
99.90%
|
||||||
|
Battery charge/discharge efficiency
|
97.50%
|
||||||
|
safeguard
|
|||||||
|
DC insulation resistance detection
|
yes
|
||||||
|
Residual current detection
|
yes
|
||||||
|
DC reverse polarity protection
|
yes
|
||||||
|
AC/DC lightning protection
|
Level 2
|
||||||
|
DC switching
|
yes
|
||||||
|
Anti-islanding protection
|
yes
|
||||||
|
AC Overcurrent Protection
|
yes
|
||||||
|
AC Short Circuit Protection
|
yes
|
||||||
|
AC overvoltage protection
|
yes
|
||||||
|
Ground fault detection
|
yes
|
||||||
|
Basic Information
|
|||||||
|
Operating Temperature Range
|
-25 ~ + 60℃
|
||||||
|
Relative working humidity
|
0～100 %RH
|
||||||
|
Maximum working altitude
|
4,000m
|
||||||
|
Cooling method
|
Natural cooling
|
||||||
|
Display
|
LED / App / Web
|
||||||
|
Methods of communication
|
CAN / RS485 / WIFI / 4G / LAN
|
||||||
|
weight
|
20kg
|
||||||
|
Dimensions ( Width * Height * Thickness )
|
522*416*177.6mm
|
||||||
|
Ingress protection
|
IP65
|
||||||
|
Installation
|
Wall mounting
|
||||||
