Function Features:

1. Reasonable layout and simple operation; 2. Fully automatic continuous slicing function; 3. Available in continuous, step, and single-slice modes; 4. Adjustable slicing speed.

2. The device features a 4.3-inch touch screen design, which is easy to understand and offers both Chinese and English language options.

3. External control panel for easier operation; (optional)

4. Two independent memory functions for location settings, with multiple configuration methods.

5. Digital positioning of the clamp head, automatically reach the coordinate position upon inputting the coordinates.

6. Semi-automatic sensing function for intelligent perception, which improves work efficiency. By simply turning the hand wheel half a turn, the repair operation can be completed. The entire process requires no other operations. After completing the semi-automatic repair, turning the hand wheel all the way will automatically switch to the slicing mode.

7. Unique sample retraction function with adjustable retraction thickness, avoiding damage caused by reverse friction between specimen tissue and the slicing knife, making the blade more smooth and simultaneously extending the blade's service life.

8. Crossed ball bearing double guide rail design, sturdy structure and stable performance.

9. Adopts advanced speed regulation methods, with minimal vibration and low noise.

10. A variety of tissue clamps are available, with bidirectional sampling, suitable for different hardness and different shapes of samples;

The knife holder body can accurately move laterally, ensuring the use of the entire blade edge without moving the blade with the fingers, avoiding the risk; at the same time, each blade can be cut into three parts of the wax block tissue, making the service life of the blade three times that of the original, compatible with wide blades and narrow blades, with built-in knife protection and retraction device.

12. The surface of the body is made of metal powder coating, which is strong, corrosion-resistant, and has smooth lines, giving it a elegant appearance.

13. The hand wheel can be locked at the upper and lower positions to make the slicing work safer and more convenient.

14. The knife stand uses a base with a tail-like slot structure, which allows for more precise and stable front-to-back movement and locking.

15. Large capacity waste chute with magnetic function for easy disassembly and installation, ensuring clean and hygienic slicing operations.

16、withA 0-position sample positioning system with X/Y axis adjustment, capable of ±8 degree horizontal positioning of samples.

Technical parameters:

1. Slicing thickness: 0μm～100μm (The best slicing effect is achieved at 3~5um)

2. Setting range: 0μm～5μm, increment value 0.5μm

Increment value from 5μm to 20μm, 1μm step

Increment value from 20μm to 60μm, step size 5μm

Increment value 10μm at 60μm～100μm

You can directly input numbers by touching the screen.

3、Reshaping thickness: 0μm～800μm

4. Setting range: 0μm～10μm, increment value 1μm

Increment value from 10μm to 20μm, 2μm step

Increment value from 20μm to 50μm, step size 5μm

Increment value 10μm between 50μm and 100μm

Increment value from 100um to 800um, step size 50um

You can directly input numbers by touching the screen.

5. Sample retraction: adjustable from 0 to 250 μm

Specimen horizontal travel: 30mm, specimen vertical travel: 70mm.

Slicing accuracy: ±5%

8. The largest clamp-type clamp head size: 55mm*45mm

9. Blade angle 0~15°

10、Language Types: 2 (Chinese, English)

11. Input Power: AC220V/110V, Frequency: 50/60Hz

12、Product Volume"; 590×440×320mm

13、Product weight: 35kg

Packing Size Information:

Gross weight: 45kg

Outer Box Size: 695*525*480mm
