| small metal copy/abcd/433 | ¥0.0 | 5332 piece available |
|
| small metal copy/abcd/315 | ¥0.0 | 3553 piece available |
|
A new item has been added to your Shopping Cart. You now have items in your Shopping Cart.
Technical parameters:
| Working Voltage: DC12V (12V battery 1 piece) | Working Current: 10mA@12V |
| Radiation power: 10mw@12V | Modulation Mode: ASK (Amplitude Shift Keying) |
| Frequency: 315, 433MHz (sound table stable frequency, other frequencies can be customized) | Transmission distance: 50-100m (open space, receiver sensitivity at -100dBm) |
| Encoder Type: Fixed Code, Learning Code, Rolling Code | Dimensions: 54.3*30*14mm (excluding the push-on cover) |
Application: Motorcycle and car security products, home security products, remote control switches, security alarm systems, remote control door locks, remote control electric roll-up doors and windows, industrial control, and other wireless remote control products.
Applicable Scope:
Wireless control of light bulbs, garage doors, motors, and home appliance switches.
Technical indicators:
1. Working Voltage: 12VDC
2. Static Current: ≤7mA
Contact Capacity: 7A 240VAC | 10A 24VDC
4. Working Frequency: 315MHz, 433.92MHz, Special Frequencies Can Be Customized
Control Mode: Switched Type, Self-locking Type, Mutual Locking Type
