No.
|
Name
|
Function
|
Material
|
|
1
|
Top Rubber |
Protect the linling tensile member
|
CR HNBR
|
|
2
|
Tensile Member |
Core material to pass the dynamic force
|
Glass Filber
|
|
3
|
Teeth Rubber |
Protect the tensile member and maintain the shape of the rubber
|
CR HNBR
|
|
4
|
Teeth Fabric |
Maintain the shape of the adhesive
|
Elastic Fabric
|
| Feature |
|
| Section Size Synchronous Belt for Automobile |
|
Type
|
Pitch(mm)
|
Tooht Height（mm）
|
Belt height (mm)
|
|
ZA
|
9.525
|
1.91
|
4.10
|
|
ZB
|
9.525
|
2.92
|
4.50
|
|
ZH
|
9.525
|
3.50
|
5.50
|
|
YH
|
8.00
|
3.04
|
5.20
|
|
ZR
|
9.525
|
3.20
|
5.70
|
|
YS
|
8.00
|
2.00
|
5.10
|
|
ZS
|
9.525
|
3.53
|
5.70
|
|
YA
|
8.00
|
2.95
|
5.20
|
|
ZAS
|
9.525
|
2.32
|
4.62
|
|
ZBS
|
9.525
|
2.76
|
5.06
|
|
S8M(YU)
|
8.00
|
3.05
|
5.30
|
|
FS
|
9.525
|
3.05
|
5.35
|
|
MY
|
8.00
|
3.06
|
5.20
|
|
MR
|
9.525
|
3.54
|
5.69
|
|
RU
|
9.525
|
3.41
|
5.40
|
|
ZLB
|
9.525
|
2.70
|
5.05
|
