jewelry scale electronic scale kitchen scale electronic scale

Product Information:●Overload protection function● Blue Backlight ● Weight Unitgandcalcium carbonateouncegn

●Auto Shut-off Time1minute

● Use ambient temperature0°C – 40°C (32°F - 104°F)

●Power supply7-cell battery●Low Voltage DisplayLO_

● Overload DisplayO_Ld

This item: English instruction manual, English case key

Correction Method
Press the "mode" key for 3 seconds without releasing, and the display will show "CAL" when you let go. Then press the "mcde" key again until the display shows "500/2000g". At this point, place the 500/2000g weight on the tray, and after 3 seconds, the display will show "500.00/2000.0g". The calibration is complete. (If the weighing is inaccurate due to excessive temperature differences or other reasons, use this function.)

Notes
1. Gently remove the tray cover, place the scale body on a stable and vibration-free surface, and use it in a non-windy environment.
2. Do not place any object weighing more than the rated weight on the pallet, as this may damage the sensor. When placing objects, please do not impact the weighing pallet, handle with care, and be gentle. (This is a general caution for pocket scales. This machine is equipped with pressure protection settings that can withstand about 100 pounds of pressure without damage).
3. When using this product, do not use a mobile phone within 50CM of the scale, as this may affect the use of the product;
4. When the display shows the battery symbol, please replace the battery immediately.

Operating Method

On/Off

(1) Place the electronic scale on a stable desk surface, then press the on/off key ('ON/OFF' key or ' ' key) to turn it on. The display will show the startup screen (the backlight will automatically turn on at the same time), and after about 1 second, it will show '0.0' (or '0.00', '0.000'), which means it is ready for normal use.

(2) Power off by pressing the ON/OFF key or the " key once when the device is on.

(3) In order to extend the battery life, if there is no operation or the display screen shows no changes in numbers while the device is on, the system will automatically turn off the power after 60 seconds.

Zero/Reset Function

(1) After turning on the machine, if the display does not show "0.0" or "0.00", press the "TARE" key (or the "T" key) to display the zero point, and then you can use it normally.

(2) If you want to use other containers for weighing, please first place the container on the scale plate, and then press the "TARE" key (or "T" key) to display "0.0" (or "0.00," "0.000"). After that, put the items in the container, and the actual weight of the items will be displayed. When you remove the container, a negative number will be displayed. Press the "TARE" key (or "T" key) to zero it.

Unit Conversion Function

In a normal weighing state, press the 'MODE' key (or 'M' key) in sequence to display the weight in different unit modes. For example: g.oz.dwt.ct.gn.

Accumulation function

Under normal weighing conditions, place an item on the scale plate. After the weight display stabilizes, press the accumulation key ("ADD" key) once, then remove the item and place another item on the scale plate. After the weight stabilizes, hold down the accumulation key ("ADD" key) without releasing it, and the display will show the total weight of the two items. You can accumulate the weights of multiple items in turn.

Counting function

3. PCS：

All items must be the same weight

Under normal weighing conditions, place a certain amount of sample (system pre-sets 25.50.75.100 four sample quantities for selection) on the scale plate, hold down the "PCS" key without releasing it, and after 2 seconds, the display will show the sample quantity. Then release the "PCS" key, press the "MODE" key (or "M" key, "UNITS" key), you can switch to different sample quantities. After selecting, press the "PCS" key to confirm the sample quantity and enter the counting state. If you need to change the sample quantity, you can re-set the above steps; in the counting state, press the "MODE" key (or "M" key, "UNITS" key), the system will exit the counting state and return to the normal weighing state to display the weight value.

Calibration:

   1. The scale has measurement ranges of 2000g, 1000g, 500g, 300g, 200g, 100g, and 50g.

  2. Press and hold the [Model] button for a long time until the word 'CAL' appears, then display the calibrated weight for this machine.

  3. Place the required weights on it, and then press the [ON/OFF] button.

 4. Display 'PASS' to use normally.

5. Troubleshooting

 The main reasons for inaccuracies and malfunctions are usually due to low battery power, incorrect calibration, overloading, or operating on an unstable surface.

 "[DISPLAY] Indicates the removal of errors

 【OUT2】represents recalibration.

 [EEEE] indicates excessive weight, and you should immediately remove the excessively heavy items.

 [UN2T] represents weighing on a more stable platform

Under normal weighing conditions, place a certain amount of sample (system pre-sets 25.50.75.100 four sample quantities for selection) on the scale plate, hold down the "PCS" key without releasing it, and after 2 seconds, the display will show the sample quantity. Then release the "PCS" key, press the "MODE" key (or "M" key, "UNITS" key), you can switch to different sample quantities. After selecting, press the "PCS" key to confirm the sample quantity and enter the counting state. If you need to change the sample quantity, you can re-set the above steps; in the counting state, press the "MODE" key (or "M" key, "UNITS" key), the system will exit the counting state and return to the normal weighing state to display the weight value.
