| Specification | A: Total length | B: Height | C: Width | D: Screw length | E: Screw diameter | F: Chuck diameter | Clamping Range |

|
|||||||||||||||||||
| 4 | 200mm | 105mm | 35mm | 170mm | 13.5mm | 28.5mm | 100 million | ||||||||||||||||||||
| 5 | 250mm | 110mm | 40mm | 205mm | 13.5mm | 28.5mm | 125mm | ||||||||||||||||||||
| 6 | 280mm | 125mm | 40mm | 245mm | 15mm | 28.5mm | 150mm | ||||||||||||||||||||
| 8 | 330mm | 145mm | 45mm | 285mm | 15mm | 28.5mm | 200mm | ||||||||||||||||||||
| 10 | 380mm | 155mm | 50mm | 335mm | 18mm | 35mm | 250mm | ||||||||||||||||||||
| 12 | 430mm | 165mm | 60mm | 375mm | 18.5mm | 35mm | 300mm | ||||||||||||||||||||
