Enclosure: light aluminum alloy enclosure, light and solid, high heat dissipation rate, fully sealed design is suitable for use in the environment with poor working conditions.
Reverse protection device: it is a special electrical device. When the power connection is wrong, the control circuit cannot work.
Limit switch: there are limit switch devices for lifting at noon, which make the motor stop automatically to prevent the chain from exceeding and ensure safety.
24V/36V device: in case of quick power leakage during operation, it can prevent accidents.
Bang magnetic braking device: the magnetic device can brake instantly when power is cut off.
Chain bag: lightweight, beautiful, durable >
Chain: imported FEC80 superstrong processing alloy steel chain.
| model model | HHBB | ||||
| 7.5-03 | 10-04 | 15-06 | 20-08 | 25-10 | |
|
capacity(ton) Rated load |
7.5 | 10 | 15 | 20 | 25 |
|
lifting Speed (m/min) Hoisting speed |
1.8 | 2.8 | 1.8 | 1.8 | 1.8 |
|
motor power(kw) The motor power |
3 | 2 * 3.0 | 2 * 3.0 | 2 * 3.0 | 2 * 3.0 |
|
rotation speed(R/min) speed |
1440 | ||||
|
insulation grade Motor insulation grade |
F | ||||
|
travelling speed(M/min) The running speed |
Slow 11 m/min & amp; Express 21 m/min | ||||
|
power supply Working voltage |
3 - phase 380 v 50 hz | ||||
|
control voltage The control voltage |
24 v / 36 v / 48 v | ||||
|
No. Of load chain The chain back to the number of |
3 | 4 | 6 | 8 | 10 |
|
Of them the Spec. load chain The chain specification |
Phi is 11.2 | Phi is 11.2 | Phi is 11.2 | Phi is 11.2 | Phi is 11.2 |
|
The.net Weight (kg) The net weight |
176 | 300 | 382 | 482 | 503 |
|
I - beam(mm) I iron |
/ | / | / | / | / |
1. Description of supply
The primary source of goods, supply stability, quality assurance, long-term warehouse stock.
2. About the size
The measurement is artificial and the error is within 1mm.
3. About color
All of them were shot in real life, and the color difference caused by light problems was normal.
4. About customer service
Monday to Saturday (except holidays) from 8:30am to 10:00pm online, if you can't contact customer service, you can call or QQ contact!
5. About after-sales service
Because this store product kind is various, the product quality assurance each has the difference, the concrete please contact the customer service!
6. About delivery
Due to the special products of our store, most of the goods are heavy. Except for some products that support express delivery, other products support logistics. We will arrange the delivery as soon as possible. In addition to customized products, we will deliver the goods within 1-3 days. Please understand!
