This device is made of high-strength aluminum alloy, featuring a beautiful appearance, compact design, small size, and light weight. It uses a two-stage gear mechanism, resulting in smooth operation and low noise. The components have high strength, and they are primarily constructed from high-alloy steel materials, processed using special techniques, offering excellent high-strength and wear resistance.
Model HHBB 0.5-01S 01-01S 01-02S 1.5-01S 02-01S 02-02S Capacity (Ton)
Rated Load 0.5t 1t 1t 1.5t 2t 2t Lifting Speed (m/min)
Lifting Speed |||| 7.2 |||| 6.8 |||| 3.6 |||| 8.8 |||| 6.6 |||| 3.4 |||| Motor Power (kW)
Motor Power |||| 1.1 |||| 1.5 |||| 1.1 |||| 3 |||| 3 |||| 1.5 Rotation Speed (r/min)
Speed 1440 Insulation Grade
Motor Insulation Class Class F Traveling Speed (m/min)
Running Speed Slow: 11 m/min & Express: 21 m/min Power Supply
Working Voltage 3-Phase 380V 50Hz Control Voltage
Control Voltage 24V / 36V / 48V Number of load chains
Number of Chain Loops 1 1 2 1 1 2 Specification of Load Chain
Chain Specifications φ6.3 φ7.1 φ6.3 φ10.0 φ10.0 φ7.1 Net Weight (kg)
Net weight 47 61 53 108 115 73
1. Supply source description
The manufacturer has direct supply sources, stable delivery, guaranteed quality, and long-term inventory in the warehouse.
2. Regarding size
The size is measured manually, with an error of no more than 1mm.
3. Regarding Colors
All images are taken with real objects; color differences due to lighting issues are normal.
4. Regarding customer service
Monday to Saturday (excluding holidays): Online from 8:30 AM to 10 PM. If you cannot reach customer service, please call or contact QQ!
5. Regarding after-sales service
Due to the wide variety of products in our store, each product has different warranties. For details, please contact customer service!
6. Regarding shipping
Due to the special nature of our products, most items are heavy. Except for a few products that can be shipped via courier, all other products can be delivered through logistics services. We will arrange shipment immediately. Except for custom-made items, orders are typically shipped within 1–3 days. We appreciate your understanding!
