Product descricption --Ppr pipes and fittings(cold and hot water supply)
Features of PPR fittings:
Material of ppr fittings: Random Polypropylene,Hyosung 200P, SK, Borealis……
Size ranges of ppr pipes: from 20mm to 160mm
Size ranges of ppr fittings: from 20mm to 160mm
Pressure Rating of ppr fittings: 1.25MPa, 1.6MPa, 2.0MPa, 2.5MPa
Colors of ppr fittings: white, green, grey, light brown or other colors at your request
Connection of pp-r fittings: socket fusion joint, electro fusion joint or transition joint
Standard of pp-r fittings:GB/T18742.2-2002,GB/T18742.3-2002,GB/T13663-2000,GB/T5836.1-2006,DIN8077, DIN8078 Cirtification of pp-r fittings: ISO9001:2008, ISO14001, CNAS C048-Q, IAF
Specification for PPR pipes abd fittings
Product Code | Pressure Grade | Size | Product Code | Pressure Grade | Size |
xs20-1 | PN10/S5 | 20×2.0 | xs20-3 | PN16/S3.2 | 20×2.8 |
xs25-1 | 25×2.3 | xs25-3 | 25×3.5 | ||
xs32-1 | 32×2.9 | xs32-3 | 32×4.4 | ||
xs40-1 | 40×3.7 | xs40-3 | 40×5.5 | ||
xs50-1 | 50×4.6 | xs50-3 | 50×6.9 | ||
xs63-1 | 63×5.8 | xs63-3 | 63×8.6 | ||
xs75-1 | 75×6.9 | xs75-3 | 75×10.3 | ||
xs90-1 | 90×8.2 | xs90-3 | 90×12.3 | ||
xs110-1 | 110×10 | xs110-3 | 110×15.1 | ||
xs160-1 | 160x14.6 | xs160-3 | 160x21.9 | ||
xs20-2 | PN12.5/S4 | 20×2.3 | xs20-4 | PN20/S2.5 | 20×3.4 |
xs25-2 | 25×2.8 | xs25-4 | 25×4.2 | ||
xs32-2 | 32×3.6 | xs32-4 | 32×5.4 | ||
xs40-2 | 40×4.5 | xs40-4 | 40×6.7 | ||
xs50-2 | 50×5.6 | xs50-4 | 50×8.3 | ||
xs63-2 | 63×7.1 | xs63-4 | 63×10.5 | ||
xs75-2 | 75×8.4 | xs75-4 | 75×12.5 | ||
xs90-2 | 90×10.1 | xs90-4 | 90×15.0 | ||
xs110-2 | 110×12.3 | xs110-4 | 110×18.3 | ||
xs160-2 | 160x17.9 | xs160-4 | 160x26.6 |
Application Area of PPR pipe fittings:
1. Cold and hot water systems of residence and commercial buildings.
2. Transportation of industrial water supply and chemical materials.
3. Pure water pipe system.
4. Piping networks for rainwater utilization systems.
5. Irrigation systems for gardens.
6. Transportation system of drinking water production.
7. Piping networks for solar plants.
8. Other pipes in industry and agriculture
PPR pipes & fittings Characteristics:
1. Well heat resistance ability
The pipes can be used for a long time while the working temperature of water is 70°C. They can be used for a short time while it reaches 95°C. The softening temperature is 140°C.
2. Well insulation ability
3. Long life span
Under normal conditions of temperature and pressure, PP-R pipes can be used for over 50 years.
4. Little resistance for water flow
The inner walls of PP-R pipes are smooth and limescale will not be formed there. The wear resistance factor is only 0.007, considerabally lower than the matel pipes. The ability for carrying water for PP-R pipes increases by over 30% than the metal pipes with the same size.
5. Environmental
During the process of production, construction and use, PP-R pipes will not make any pollution to the environment.
6. Economical
The price for PP-R pipes is almost the same with the galvanized pipes. With convenient construction, they are more cheap.
7. Light weight
The density of PP-R pipes is 0.89-0.9g/cm, only 1/8 of the steel pipes, 1/10 of copper pipes. The light weight will reduce the transportation cost and the construction intensity.
8. Healthy
The materials of PP-R pipes are formed with just two elements, that is, Carbon and Hydrogen. The sanitation performance of the materials has passed the examination by the government authority.
9. Well corrosion-resistance
Except for few oxidents, the pipes can endure the erosion of many kinds of chemical materials. The pipes will not be rusted, get eroded, breed the growth of bacteria.
10. Little expansion force
The flexible moludus of PP-R materials is small. So the expansion force formed with the change of temperature is little. They are suited for the installation of inside walls and concealed foor construction.
11. Complete accessories
PP-R pipe system have a full set of accessories and can meet the requirements of general project.
12. Solid connection
PP-R pipe system adopts the hot-welding way for connection. The pipes and fittings are linked together The tensile, bending and impact intensity at the interface is bigger than the pipe intensity, avoiding the hidden danger of water leakage.
