Zhejiang Zheng Rong Machinery Co. Ltd. 13yr.
Contacts:马帅Chat
Mobile:86-15268696111
E-mail:rongzhengjx@hotmail.com
|
型 No. |
LJ - 800. |
LJ - 1600. |
LJ - 3200. |
|
Vertical lift at rated load |
800 kg |
1600 kg |
3200 kg |
|
Rated load level pulling |
1200 kg |
2400 kg |
4000 kg |
|
Maximum hand force at rated load |
343 n, or less 35 KGF or less |
441 n, or less 45 KGF or less |
441 n, or less 45 KGF or less |
|
The handle reciprocates the maximum stroke of the rope |
52 mm or higher |
55 mm or higher |
28 mm or greater |
|
Machine weight |
6 kg |
12 kg |
23 kg |
|
Installation dimensions |
420 * 80 * 80 mm |
550 * 100 * 100 mm |
660 * 110 * 380 mm |
|
Steel wire diameter |
8 mm |
11 mm |
16 mm |
|
Weight of wire rope |
7 kg |
13 kg |
26 kg |
|
Project Item Type of Model |
LJ - 5400. |
|
|
Rated capacity |
5400 |
|
|
Forward hand power(N) |
745 |
|
|
Forward travel(mm) |
≧ 30 |
|
|
Nominal diameter of wire Rope diameter(mm) |
20 |
|
|
Steel wire rope safety factor load capacity |
5 |
|
|
Static Safety factor & The static load capacity |
5 |
|
|
MAX. Traveling load(kg) |
8000 |
|
|
Body weight Net weight |
56.5 |
|
|
MAX overall size |
a. |
930 |
|
B |
480 |
|
|
C |
152 |
|
|
L1 (cm) |
68 |
|
|
L2 (cm) |
112
|
|
