This card has two modes of transmitting and receiving, when in use, only with a model, or to receive a signal, either to transmit signal, as Internet speed depends on the speed of your access to the!
using a wireless network card function
for receiving wireless router signal, WIFI signal.
use WiFi emission features
for at home without the router, realize multiple WiFi devices to share Internet access, this product is inserted into the computer can access the Internet, by setting send WiFi signal, wireless network card desktops, laptops, tablets (MID), iPad, and with WiFi enabled mobile phone, after setting the received signal to share Internet access, at this time, the product is equivalent to a USB wireless AP Router, buy a router.
802.11b:1,2,5.5,11Mbps;
6,9,12,18,24,36,48,54Mbps; 802.11g;
802.11n: (20MHz) MCSO-7, up to 72Mbps, (40MHz) MCSO-7, up to 150Mbps
Modulation mode: OFDM
Peak rate: 150Mbps
Peak throughput rate: 90Mbps
Intelligent power management function
security model: 802.11 b/g/n, WPA, WPA2, WMM, WMM-PS, WHQL, Cisco, CCX
| Hardware | |
| Chipset | RT5370,1T1R mode Ralink |
| Interface Host | Type, A USB2.0/1.1 |
| LEDS | Activity Link/ |
| RF | |
| Antenna | PCB antenna Built-in |
| Frequency | ISM, band. 2412~2483.5MHz |
| Power Transmit | 802.11b:19+/-1.5dBm; 802.11g:14+/-1.5dBm; 802.11n: (HT20), 14+/-1.5dBm, 802.11n: (HT40), 14+/-1.5dBm. |
| Sensitivity Receive |
802.11b:-84+/-1.5dBm@11Mbps; 802.11g:-69+/-1.5dBm@54Mbps 802.11n: (HT20), -67dBm@M8C7802.11n: (HT40), -63dBm@MSC7. |
| Software | |
| System Operation | CE/2000/XP/Vista Windows; 2.6.X Mac; OS X Linux |
| Security |
64/128bit WPA, WEP, WPA2802.1X, Cisco CCS V1.0,2.0 and V3.0 Compliant. and802.11i |
| Conditions Operation | |
| Range* Voltage | 5.0V DC + 5%, < 130mA |
| Temperature Operating | 0 degrees C -40 C |
| Temperature Storage | -20 C -70 C |
| Humidity Operating | RH 95% (Non-Condensing) |
| Humidity Storage | RH 95% (Non-Condensing) |
| Specification Physical | |
| Dimensions | 32.0*14.2*7.3mm |
