Infrared Thermometer

Name

Function

Description

F-1

C / Fahrenheit Conversion

Temperature unit setting

F-2

Body temperature / temperature conversion

Ear temperature / matter temperature model selection

Show BODY for ear temperature / forehead mode

Show FACE as the material temperature / ear temperature model

F-3

Clock setting

After setting the clock to display room temperature, the clock and room temperature alternately display, time interval 30 seconds

F-4

Temperature deviation adjustment

According to the specific user of different skin color, infrared intensity emitted from when you measure the temperature deviation, the deviation can be set by the function value, enter the sub menu after the front no symbol represents - positive, negative, the range of - 3 DEG C, resolution 0.1 C (only applicable to forehead temperature measurement mode)

F-5

Orange backlight setting range

Orange backlight range, the default value of 37.5 -37.9 C, can be set to a range of + 3

F-6

Red backlight setting range

Red backlight range, the default value of 38 C -42.9 C, can be set to a range of + 3 degrees Celsius when the orange backlight setting value and the red backlight setting value overlap, red is worth priority.

Special tips

Reason

processing method

ERR

Ambient temperature exceeds 10 degrees Celsius to 40 degrees Celsius

Place this product in 10 degrees Celsius to 40 degrees Celsius environment 30 minutes

HI

Temperature object temperature > 42.9

Please check the measuring object before measuring

LO

Temperature object temperature < 32

Please check the measuring object before measuring

Full display

Can not boot or boot after long time zooma

1 remove the battery, after 30 seconds to reload the new battery 2 replacement of the new battery
