Scope of Application
Handheld hoists are primarily used in factories, mines, construction sites, ports, shipyards, warehouses, and other locations. They are employed for installing machinery and lifting goods, and particularly demonstrate their advantages in outdoor and power-free environments.
Operation Instructions
1. It is strictly prohibited to use it under diagonal tension with excessive load.
2. It is strictly prohibited to operate using any power other than human effort.
3. Before use, ensure that all components are intact, the transmission parts and lifting chains are well lubricated, and there is no abnormal idle operation.
4. Before lifting, check whether the upper and lower hooks are securely attached. The lifting chain should be hung vertically, with no twisted links. The lower hooks of a double-row chain must not turn over.
5. The operator should stand in the same plane as the chain wheel and pull the chain, causing the chain wheel to rotate clockwise, which will lift the heavy object; pulling the chain in the opposite direction will cause the heavy object to descend slowly.
6. When lifting heavy objects, it is strictly prohibited for anyone to perform any work or move under the object to avoid major accidents.
7. During the lifting process, whether the load is rising or falling, when pulling the hand chain, apply force evenly and gently. Do not use excessive force to prevent the hand chain from jumping or the clamping ring from getting stuck.
8. If the operator notices that the hand force exceeds the normal force, they must immediately stop using it to prevent damage to the internal structure and avoid any falling object accidents.
After the heavy object lands safely and firmly, then remove it and pull the winch hook down.
10. After use, handle with care, store in a dry and well-ventilated place, and apply lubricating oil before keeping it safe.
