The built-in rechargeable lithium-ion battery, using the machine for the first time, please charge can be charged in the following ways:

1) connecting computer charge using USB connection with your computer.

2) fully recorded, video can also charge (external or USB 5V charger mobile treasure).

3) charging blue lights bright, full of red and blue lights bright said after charging full, (after the red and blue light, refillable 30 minutes or so will ensure the battery 100% is full).

Note 1: when the battery is low, t Kalu full, DV red and blue lights flashing after 5 seconds will shut down directly into protected (save the file and automatically shut) the recording file has been saved, at this time, please charge the native.

2: power on the card, red and blue lights flash simultaneously for 5 seconds automatically shut down.

3: power without any pattern, 1 minute automatic shut down.

First three uses:

USB TV wire, 1: can be plugged into your computer for charging and data transfer. 2: you can insert the TV OUT display. 3: you can insert external DV 5V charge was recorded.

720P videos no Flash:

Click the ON OFF button for power on, power on the blue lights stay lit, click on the switch 1, the blue lights Flash 3 times out of 720P videos, video lamp does not tip, automatically save the piecewise continuous 5-minute video, cycle cover, then click the switch button again to stop the video, back to blue light illuminated steady standby mode.

1080P videos no Flash:

Power blue light long standby mode, press mode button 1 time, red and blue light 1080P long video recording mode, click the switch button 1 time, blue light red light blink 3 times off, 5-minute 1080P video automatically segment your saved videos in a row, cycle cover, press the switch once again to stop recording and return to the standby mode.

Photos 12 million:

Power standby mode press mode button 2 long red light to photo mode, then press the power button once the red light Flash, Photo 1, 12 million pixels (4032X3024) automatically saved.

Infrared light opens closes:

Open: any power on standby mode, press and hold the on/off button for 2 seconds the red light flashing 2 infrared night vision light turn on, night-vision video.

Close: close the infrared night vision light and any standby mode, press and hold the on/off button for 2 seconds, red light flashes 3 to close the infrared night vision light.

Motion detection mode (720P-1080P):

720P motion detection: blue light under standby mode, press and hold the mode button for 3 seconds blue light red light blink after 3 off on motion detection recording mode, detects objects after the move, red and blue lights flash for 720P mobile videos, 5-minute, automatic packaging saved, cycle cover, No objects have been on standby to no power or t Kalu full. (Click any button 1 to exit motion detection mode)

1080P motion detection: in the red and blue lights always 1080P the video mode, press mode button 3 sec red flashing 3, blue lamp light red flashing 3 both entered on mobile video mode, detect objects after the move, red and blue lights flash for 1080P mobile videos, 5-minute, automatic packaging saved, cycle cover, No objects have been on standby to radio or t Kalu full. (Motion detection mode press any button 1 time).

Full record:

Insert the t card, external insert USB TV lines, external 5V USB power charging or treasure, machine directly into the 720P camera mode not manually stop recording until the card is full or not, you can also manually stop recording any mode.

TV OUT mode:

Connect the USB TV cable, power on the TV screen can see the image through the TV screen, you can now take pictures, video, and motion detection.

Reset:

Machine panic, key is not valid, not used correctly, can be inserted using a pointed object to reset hole to reset the camera, reset can be used normally.

Shutdown:

Stop (video, photos, motion detection) function mode, you need to shutdown, press on/off button for 6 seconds or so, to see red and blue lights all but shut down. Or in the standby mode does not use any function case, stand 1 minute automatic shut down.

Modify the settings on their own time:
Click the right mouse button in the desktop state once, select-new-text document on the desktop to create a document, open the text document, needed to compile your own time format (years and days

Minutes) 20150908182568 y save the text file, and name new text amended to read:

(TIMERSET), drawing, plugged into the computer via a USB data cable and the machine connection, there u

Mode to copy the saved text file to the root directory of the USB flash drive mode, as shown in figure ()

And then unplug the USB cable, press a button the remote control turn on DV, watermarks are written to RTC time machine

Keep, (plugged in to a computer read again u, TTMERSET files disappears. Takes no time to watermark

Mode of operation, which is the difference between the y and n at the end of it. Content is formatted as follows: reference style:

1:20150908182568 y (watermark shows)

2:20150908182568 n (No watermark shown)

Note:

A ... Please be sure to confirm that the product is inserted T-flash (Micro SD) card. If no card double Flash not work properly with red and blue lights.

B ... in an environment of ample lighting, photographic camera to, and subject matter remained 50cm the distance, this will get the correct and natural colors, features a clear, stable image picture.

Connected to the computer:

Power on standby and shutdown, are directly connected to the computer, connected to the computer can be used as a USB memory stick to use, free file copying, pasting, deleting, formatting u disk.

Leave the unit plugged into a computer USB port, after a few seconds the computer will pop up a removable disk logo, blue indicator light identifies USB devices for data transmission, red indicator light for charging, red light out for the full.

Tip:

A. After this machine is connected to the computer, if the computer does not recognize or do not eject the removable disk identified by 30 seconds, reset plug once again.

B. it is recommended that t-card reader read the video file to play it directly, and directly through a USB connection playback video files saved in this video in the built-in memory, might be because the amount of data is too large, transmission can not keep up, resulting in playback is not smooth.



Note: after each time you use your battery recharging, about it should be around 2-3 hours to complete full and rushed enough red and blue lights all bright red as possible after 30 minutes, ensure the battery is full. This product is a true HD high definition DV products power current bipu, shell material-zinc alloy, and used products may have some fever is normal, don't have to worry about bad products, is the result of long after aging test to ensure that no quality problem shipments.
