Pro: more new models available in mong pu albums or classified check.
Brand:It's easy to get TYT. TC - 100.
Standby time: 3-7 days.
Packing number: 40 sets
Channel scope:400-400.
Transmitting power: 10W.
Memory channel:16 channel
Product size: 132*59*32mm without antenna.
Battery capacity: 48000mAh polymer lithium battery.
Product weight:Machine head + battery + antenna 0.270g[original package with color box 0.490kG]
Specification parameters:
Frequency range | 400.000 to 470.000 MHz |
Channel number | 16 |
The power supply voltage | 7.4 VDC |
Working temperature | - 10 ° C ~ + 50 ° C |
The antenna configuration | Loaded antenna |
The antenna impedance | 50 Ω |
Way to work | Same frequency single or different frequency. |
Receiving part | |
Frequency range | 400.000 to 470.000 MHz |
The sensitivity | 0.2 u V or less |
bandwidth | 16 KHZ or less |
Channel selectivity | 65 db or higher |
intermodulation | Acuity 55 db |
Audio output | & gt; 1 w |
Audio distortion | 5% or less |
The frequency tolerance | 5 PPM |
Receives the current | Standby 55mA call 250mA. |
Audio response (300-3000hz) | + 7 to 12.5 dB |
Reference frequency | 21.700 MHz |
Launch part | |
Frequency range | 400.000 to 470.000 MHz |
Modulation sensitivity | 8 ~ 12 mv |
Radio frequency power | P 5 w |
Modulation method | 16 kf ¢3 e |
Stray rf components. | 7.5 mu W or less |
Modulation noise | & lt; - 40 db |
Modulation distortion | & lt; 5% |
The frequency tolerance | 5 PPM |
The largest deviation | + / - 5 KHZ or less |
Emission current | 1500 ma or less |
Audio response (300-3000hz) | + 6.5 ~ - 14 db |
Adjacent power | 65 db or higher |
