The factoryV belts, toothed belts, cutting belts, pk belts, timing belts, synchronous belts, pk multi-wedge belts, triangular belts
|
Tooth Tooth shape Code
|
Pitch the Pitch (MM)
|
Tooth Height (MM)
|
Belt Thickness (MM) thick
|
|
先生
|
9.525
|
3.54
|
5.69
|
|
ru
|
9.525
|
3.56
|
5.7
|
|
my
|
8
|
3.11
|
5.21
|
|
yu
|
8
|
3.109
|
5.2
|
|
za
|
9.525
|
1.91
|
4.1
|
|
zas
|
9.55
|
2.32
|
4.62
|
|
zb
|
9.525
|
2.29
|
4.5
|
|
ZBS
|
9.525
|
2.8
|
5.1
|
|
S8M
|
8
|
3.05
|
5.3
|
|
RPP
|
9.525/8
|
2.25
|
4.5
|
Automobile synchronous belt structure:
(1) the auto synchronous belt toppings are mainly made of domestic chloroprene rubber or imported hydrogenated butyl rubber as raw materials, which is equipped with a variety of auxiliary materials of different USES to make it resistant to ozone, oil, high temperature and aging
(2) synchronous skeleton of automobile. The frame of automobile belt is mainly made of high-quality glass fiber wire rope imported from Taiwan as raw material, which has small expansion rate, soft and high density and high tensile strength. It is the core part of the belt that bears the main friction force
(3) the synchronous belt of the car has teeth, and the surface of the belt teeth adopts nylon 66 high elastic cloth as the protective layer, which makes the appearance clean, the tooth shape full, long service life, low noise and high temperature resistance, etc
Features of automobile synchronous belt:
(1) accurate transmission, no sliding during operation, with constant transmission ratio;
(2) the transmission is stable, with buffering and damping capacity and low noise;
(3) high transmission efficiency, up to 0.98, with obvious energy-saving effect;
(4) convenient maintenance without lubrication and low maintenance cost;
(5) large speed ratio range, generally up to 10, and linear speed up to 50m/s, with a large power transfer range, up to several watts to several hundred kilowatts;
(6) it can be used for long-distance transmission and the center distance can reach more than 10m.
(7) compared with v-belt transmission, the preload is small and the load on the shaft and bearing is small;
