36PKRPP8M1760
undefined




R & d, production of various colors of multi - wedge belt, triangle belt. Provide all kinds of machinery, flour machine belt.



Wedge beltStructure:
Serial number
The name of the
function
material
1
The top cloth
Protects the inner layer of the tensile body
Polyester/cotton canvas
2
Buffer rubber
To withstand and protect the adhesion of the tensile body
CR, EPDM
3
The tensile body
Core materials for delivering power
Polyester, nylon
4
At the end of the glue
Maintain the shape of the tape and improve the lateral pressure performance
CR, EPDM

Wedge beltCharacteristics of the
  • Band width and thin, excellent flexibility and flexibility
  • High transmission efficiency in high speed rotation, reverse deflection and small belt pulley
  • High tension and low elongation core adhesive is adopted to maintain even tension during operation
  • Excellent heat, oil and abrasion resistance
  • Less slippage and greater transmission effect during operation
  • Low noise during operation


Section size
model
Wedge distance (mm)
Wedge Angle (o)
With high (mm)
Wedge number
The length of the
PH
1.6
40
3
3-54
540-1270.
PJ
2.34
40
4
3-36
540-18880.
PK
3.56
40
4 to 6
3-23
600-2400.
PL
4.7
40
10
3-16
900-3000.
PM -
9.4
40
17
3-8 -
1500-3000.




Features of multi-wedge belt:
1. Rubber multi-wedge belt has both the advantages of v belt and flat belt, with both the soft and strong characteristics of flat belt and the advantages of compact and efficient v belt. The main features of multi-wedge belt are as follows:
Multi - wedge belt transmission power, space phase than the ordinary V belt transmission power of 30% higher.
2. The multi-wedge belt transmission system is compact in structure. Under the same transmission power, the space occupied by the transmission device is 25% smaller than that of the common V belt.
3. Multi-wedge belt with thin body, rich flexibility, suitable for small diameter belt wheel transmission, also suitable for high-speed transmission, belt speed up to 40m/s; Small vibration, less heat, smooth operation.
4. Multi-wedge belt is heat-resistant, oil-resistant, wear-resistant, with small service elongation and long service life.
