Technical parameters
Rated Voltage: AC100V~240V±10%, 50-60Hz
Power: 550W
■ Bulb: Original Taiwan YODN 380w
■ Color temperature: 7500K
Lamp Life: 1500 Hours
Control Mode: Autonomous, Master-Slave, DMX, Voice Control
■ DMX Channels: Dual-channel operation mode, 17/21 international DMX channels for switching
■ Signal Input: Standard three-pin/five-pin signal socket input and output
Functional Introduction
■ Display: Features a 1.8-inch LCD LCD display, external wheel operation, and English and Chinese language display.
The interface displays when the device is upright, and it has an internal gravity sensor. When the device is installed upside down, it automatically flips to display the content upside down.
■ Pattern disc: 1 fixed pattern disc, 14 fixed patterns + white light, each pattern has a shake
Motion effect, pattern disc with forward and reverse fast and slow water flow effect
■ Color Palette: 1 color palette with 14 colors plus white light, each color disc can be paired with the adjacent color.
The film can be made into a semi-color effect and can flow fast or slowly in both directions.
Rainbow Disk: Includes a colorful disk with seven colors, capable of creating a dazzling rainbow effect.
■ Prism:
15+25+35 honeycomb prism combination + 8 prism, unique dual prism design, can be mutually
Combination of superimposition or separate fast and slow rotation changes to generate a unique special multi-beam effect.
■ X-axis: 540°，16-bit
■ Y-axis: 270°, 16-bit
■ 自动纠错：
Horizontal and vertical use photoelectric reset system, accidental errors can be automatically retrieved and reset.
■ Stroboscopic: Features a mechanical stroboscopic design with a stroboscopic frequency up to 1～14 times/second, providing a clear and stable stroboscopic effect.
The speed can be adjusted at will.
Focusing: 0%～100% electronic linear focusing, ultra-smooth adjustment of focal length
Fogging: 0%～100% uniform soft light fogging effect
■ Dot-Bubble System: A remote bulb control system design that allows intelligent remote control through a control panel.
The bulb is bright and shuts off, effectively extending the service life of the bulb.
■ Intelligent fan speed regulation: When the lamp is in the off state or the strobe light is closed, the fan automatically slows down.
Run, reduce the noise of the fan, create a good performance environment. When the fan fails
When this occurs, the display will indicate a fault with the fan. Within 60 seconds, the lamps will automatically turn off to protect them, effectively preventing
Due to the fault of the fan, the burning or exploding of the bubble.
■ Appearance material: Made of high-temperature resistant and fire-retardant engineering plastic injection molding
Protection Rating: IP20
■ Working environment temperature: -20°C to 40°C
Product Size: 265mm high x 323mm wide x 527mm deep
Base Size: 120mm high x 340mm wide x 270mm deep
Packing Weight : 20Kg
