Radron basketball parapet stadium fence fence is a new type of protective product designed for the stadium. Basketball court Seine with steel as the matrix, weather-resistant polymer resin for the outer layer (thickness 0.5-1.0MM), with anti-corrosion, anti-rust, acid and alkali resistance, moisture-proof, insulation, aging resistance, feel good, environmental protection, long life and other characteristics, is the traditional paint, galvanized coating film upgrade products, its surface for dipping, plastic treatment. Can be installed in the field construction, fence product is the most flexible, according to the requirements can be adjusted at any time mesh structure, shape and size. The stadium Seine is especially suitable for use as the court Seine, the basketball court Seine, the volleyball court and the sports training ground within the height of 4 meters.
Redlon basketball parapet stadium fence fenceMaterial:
1. The surface treatment of columns, bars and accessories is hot dip and dark green.(2) PVC, not cracking, but with time will slowly fade.
(3) PE raw material, is my factory recommended materials, bright color, no fading no cracking, add antioxidant preservatives.
Redlon basketball parapet stadium fence fenceProduction process:Braided welded
Surface treatment of basketball court purse Seine:The fence net is covered with PE/PVC plastic wire, and the column and frame are treated with spray and dip
Basketball court Seine color:Generally more dark green and grass green, dark green in the majority
SeineCommon specifications:
|
style |
model | highly | Center distance | post | Bar/border | mesh | The wire diameter | note |
| packaged | affordable | 2 m to 6 m | 2 m to 3 m | Phi is 60 mm * 2.0 mm | Phi 48 mm * 2.0 mm | 50 mm * 50 mm | The 3.6 mm |
|
|
packaged |
standard |
2 m to 6 m |
2 m to 3 m |
Phi 75 mm * 2.0 mm |
Phi is 60 mm * 2.0 mm |
50 mm * 50 mm |
The 3.8 mm |
recommended |
|
packaged |
enhanced |
2 m to 6 m |
2 m to 3 m |
Phi 2.5/2.75 mm * 75 mm |
Phi is 60 mm * 2.5/2.75 mm |
50 mm * 50 mm |
The 3.8 mm |
|
|
packaged |
Strong type |
2 m to 6 m |
2 m to 3 m |
Phi 75 mm * 3.0 mm |
Phi is 60 mm * 2.5 mm |
45 mm * 45 mm |
The 4.0 mm |
|
| integral | affordable |
2 m to 6 m |
2 m to 3 m |
Phi 75 mm * 2.0 mm |
Phi 38 mm * 2.0 mm |
50 mm * 50 mm |
The 3.6 mm |
|
|
integral |
standard |
2 m to 6 m |
2 m to 3 m |
Phi 75 mm * 2.5 mm |
Phi 48 mm * 2.0 mm |
50 mm * 50 mm |
The 3.8 mm |
recommended |
|
integral |
enhanced |
2 m to 6 m |
2 m to 3 m |
Phi 75 mm * 3.0 mm |
Phi 48 mm * 2.5 mm |
50 mm * 50 mm |
The 4.0 mm |
|
Note: all the above specifications can be customized according to the drawings provided by customers, we can also give you detailed design drawings!
Redlon basketball court guardrail stadium fence anti-corrosion treatment:
1. Hot dip treatment: it is the most common anti-corrosion treatment and the one with the best anti-corrosion effect. The black parts of the frame are burned at high temperature and then soaked in the PE powder tank to make the powder melt and adhere to the surface of the pipe to form a plastic anti-corrosion layer.
2. Electrostatic spraying treatment: generally, galvanized pipe is adopted, and PE powder is adsorbed to the surface of the pipe by electrostatic adsorption principle.
3, galvanized treatment: the use of chemical replacement reaction principle to make zinc adhere to the surface of the pipe to form an anticorrosive layer.
Redlon basketball parapet stadium fence fenceProduct advantages:
The product color is bright, anti - aging, anti - corrosion, complete specifications, net surface level, strong tension, not easy to be affected by external forces deformation. Site construction and installation, the product is the most flexible, according to the site requirements at any time to adjust the shape and size. Packaged Seine, simple installation, saving labor hours, low transportation cost, beautiful shape, practical. The purse Seine adopts high standard and high quality low carbon steel wire surface PVC/PE plastic treatment, anti-corrosion and anti-rust, flat surface, stretch tension! Long service life. No artificial maintenance, surface dust washed by rain off naturally.
1. The enclosure net and protective net adopt streamlined appearance: transparent, beautiful, simple and fashionable European elegant style; Color selection diversity, a variety of standard color card color choice, can meet the needs of different fields, different environments, different aesthetic groups.
2, tomahawk type connection: unique hook connection mode, tomahawk type groove design, so that the protection network without any accessories can be connected with any height of the column embedded groove, to ensure its firmness, with stronger tensile resistance and collision resistance, but also perfect display of its anti-theft function.
3. Ten-year warranty period: sufficient pre-treatment and unique high-temperature electrostatic PVC spraying process ensure even distribution of plastic layer and smoother feel of surface; Through 2000 hours anti - salt spray test, solemnly promise to ensure that the product 10 years anti - corrosion. It has self-cleaning ability under normal environment, anti-uv, no cracking and aging, no rust and oxidation, and no maintenance.
4, because the basketball court Seine can be combined in a variety of ways: and according to the different site requirements of customers, there are a variety of arc, different angles and different levels of height ladder installation, providing the most ideal solution. Can be used together with the beautiful appearance and unique design of trackless automatic translation door, forming a harmonious and perfect whole.
Redlon basketball parapet stadium fence fencesize
The basketball court is a solid rectangular plane without obstacles.
Ii. For fiba's main official competition (see section 5 of \"official competition procedure\"), the basketball court size is: 28 meters long, 15 meters wide, outfield size: 32 meters long, 19 meters wide, and the basketball court measurement starts from the inner edge of the boundary.
3. For all other competitions, the appropriate division of fiba, such as the national federation for all domestic competitions, shall have the right to approve existing basketball courts within the following dimensions: a reduction of 4 meters in length and a reduction of 2 meters in width, provided that the changes are proportional to each other.
4. The height of ceiling or minimum obstacle should be at least 6 meters.
Fifth, the basketball court illumination must be even, the luminosity must be sufficient. The placement of lighting equipment shall not interfere with the vision of the team members.
6. The size of all new basketball courts shall be consistent with the requirements stipulated by fiba for major official matches: the inner court shall be 28 meters long, 15 meters wide, and the outer court shall be 32 meters wide and 19 meters wide.
My company specializes in production, sales, installationBasketball court Seine,Tennis court purse SeineEtc.Stadium Seine, processing customization! Factory direct sales! Our factory has its own welding, dipping, system hook flower net equipment, spot supply, the same day order the same day delivery, quality assurance!
