Warm tips:

1. All products in the store are cross-border products, and domestic sales or use are not supported.

2. The color of this product is white and gun gray.

Operating instructions:

A. power input: ac100-240v 50/60hz;

2 press the power switch &ldquo of the main control board; ON/OFF 2--3 seconds start up, at this time the white backlight is always ON, the LCD screen shows 230C, at the same time the heating element starts to heat up, the number ON the LCD starts to flicker, when the set temperature is reached, the number ON the LCD is long bright, stop flashing.

3. Press power switch &ldquo of main control board; ON/OFF 0.5--1 second switching between Fahrenheit and Celsius.

4. Press the main control board power switch “ ON/OFF 0.05--0.2 seconds to switch gears, Celsius: 230--165--185--205--230 cycle. Fahrenheit: 450--330--370-- --410 --450.

⒌ in boot mode, press the power switch on the main control board & other; ON/OFF 2--3 seconds power OFF, at this time the white backlight OFF, LCD OFF, and heat stop heating.

6. Product PTC impact current: under 120V ac, the impact current of a single PTC is below 3A.

7. NTC open circuit protection function of PCBA board. Within 3 minutes after starting up with NTC open circuit, the LCD displays ERR and the heating body stops heating.
