006333 SPE-E Cutting table with ruler for cutting silicone/rubber strip

This cutter is mainly used for cutting various soft materials such as silk screen scraper strip, various rubber, silica gel strip, round rod, etc. The fixed clamp will be fixed by the cutting material, using special high-strength stainless steel sheet cutting knife for cutting, small force, precise cutting size, smooth cutting surface.

Silk screen scraping strip with good elasticity, sharp blade, small swelling rate, cutting is very difficult, and traditional rubber strip scissors can cut rubber with hardness below 65, size of 30*7 mm , when cutting 50*9 mm is very difficult, the general hand is hard to cut off.

The cutter adopts splint structure, clamp the rubber strip on the shelf, and there is 3mm cutting groove in the middle of the splint on both sides. The cutting can be completed directly by pushing and pulling along the cutting groove with special knife.

This cutter is equipped with a special stainless steel cutting knife with a sharp edge, a thin surface, 90 mm below the surface, a v-shaped surface from the blade to the top 90 mm, the width of the top is only 2 mm, the thin body is most suitable for the cutting of various strips and rods with a certain elasticity. (the common blade in the market is v-shaped 10-15mm, the cutting surface is inverted u-shaped, and the cutting thickness suddenly increases from the upper end of v-shaped blade, which makes cutting extremely laborious)

1. The cutting table is equipped with a ruler, the longest standard ruler within 80 cm, accurate cutting requires size;

2. The two sides of the tool are provided with protective plates to protect both sharp angles of the tool from harming people; The cutting tool can stand directly on the table.

3. The bearing roller shall be installed on the cutting knife head, and it will not hurt the desktop when the roller contacts the desktop during cutting;

4. Special blade, thin and sharp, quick cutting; Special handle design, comfortable grip;

5. The top positioning baffle on the right side is equipped with a fixed knob, and the cutting object can be fixed after fixing the ruler;

6. The cutting table is equipped with magnetic board baffle to clamp the cutting object and shelf baffle to reduce the size error caused by bending of the cutting object.

7. Modular structure design, simple installation, small packaging volume, and more convenient transportation.

Methods of use and precautions:

1. Move the top baffle to the ruler and fix it according to the required cutting size;

2. Place the cutting object in the cutting splint; The top is placed at the fixed ruler baffle and slightly clamped;

3. Push the three baffles to the rear baffle;

4. Turn the handle to slightly clamp the cutting material strip (note: do not clamp too tightly, because the cutting material can not be slightly extended on both sides during the cutting process, making the cutting harder).

5. Apply lubricating oil (vaseline, oil, big butter, peanut oil, etc.) to the blade and then push and pull the cutting more easily (1 bottle of lubricating butter is distributed in this machine).

6. The splint height of the cutting table is 58mm (the cutting height is most suitable within 55mm), the width of the two sides is 80mm, and the cutting groove (gap) between the two sides is 3mm; Minimum cutting thickness 3 mm, maximum cutting thickness 30 mm.
