System Technical Parameters:

A. Host System

Working Voltage: DC12V±2V

Static Current: 8mA (excluding sensor)

Working frequency: 315MHz

The operating current of the entire machine:

Output current: small light 7.5A, speaker 3A, central locking 15A

B. Remote Control Transmitter

Working Voltage: DC6V-12V

Static Current: 0mA

Launch current: 8mA

Emission Power: 10MW

Working frequency: 315MHz

Operating Guide

Set Key：

Normal operation: when pressing the short button, the headlights blink once, the horn sounds 'Bi', and the doors are locked simultaneously, immediately entering the anti-theft alert state;

In motion: press the short key once to lock the remote control door.

Alarm in progress: press the short key once to stop the alarm, and the security system will maintain its original alert status.

Unlock Key：

Alarm or Guarding: Press the short button, the headlights blink twice, the horn sounds twice, and the lock is opened at the same time. This will deactivate the alarm and return to the security guarding mode if no trigger is detected within 25 seconds. If triggered, the security guarding mode will be completely deactivated.

Mute Button:

Normal operation: Press the short button, the headlights blink once, and the doors are locked immediately. The vehicle will enter a silent anti-theft alert state. If triggered by vibration, only the lights blink, and the horn does not sound. If triggered by the side door or the Acc, the headlights blink, and the horn beeps.

Alarm in progress: press the short key once to stop the alarm.

Parking Assist Button: (Four-Button Remote Control)

In normal or alert mode: Press the button briefly, and the horn will sound for 15 seconds with the headlights flashing in sync, indicating the vehicle's location. Press any button again to stop the flashing lights and the alarm horn.

Functional Description

Set alert:

Step 1: Set the security alarm. Park the car, remove the key from the ignition, close the doors, and press the alarm button once. The doors will lock, the headlights will flash once, and the horn will sound "Bi" once. Immediately, the car will enter a security alarm state, and the engine will be locked. If the car is triggered by vibration, the alarm horn will beep intermittently for 15 seconds, and the headlights will flash simultaneously. After the alarm, the original security state will still be maintained.

Step 2: Set Silent Alarm: Park the car, remove the key from the ignition, close the door, press the button once, the door locks, the headlights blink once, and the car immediately enters the anti-theft alert state, simultaneously locking the engine. If the car is triggered by vibration, the headlights blink for 15 seconds to alert, and after the alert, maintain the original alert state.

⑶ When the vehicle is in the alarm state, pressing the button lightly or the key can stop the alarm and maintain the original vigilance state.

Emergency Alarm:

In the anti-theft alarm system, when the door is illegally opened or the vehicle is illegally started, the system will immediately cause the alarm horn to blare for 25 seconds, and the headlights will flash synchronously to alert, preventing the vehicle from starting.

3. Disarm the anti-theft alarm:

In the sound and light security system, pressing the short button once will unlock the doors, cause the headlights to flash twice, and the horn to beep twice, which will deactivate the anti-theft security.

In silent alarm mode, press the short key once to unlock the doors, flash the headlights twice, and the horn will not sound. This will deactivate the anti-theft alarm.

Emergency Call: (Emergency Alarm)

 While driving, if a criminal attempts to forcefully rob the car, the owner should hold down the button for 2 seconds. At this time, the car's headlights will flash and the horn will periodically sound to deter and call for help. Meanwhile, the car's engine will automatically shut off to prevent the vehicle from running. This action cannot be stopped by whether the vehicle has an Acc key or if the doors are open. To stop the alarm, press the button again.

5. Automatic anti-theft response: (Secondary anti-theft)

In the anti-theft alarm system, the owner may accidentally trigger the system to deactivate the alarm, and if the doors are not opened or the vehicle is not started within 25 seconds, the anti-theft system will consider it an accidental deactivation and will automatically return to the original alarm state.

6. Central Locking Automation:

After the car drives for 15 seconds, the central control lock will automatically lock to ensure the safety of passengers and property during the journey. When the car is parked and turned off, the central control lock will automatically unlock. While driving, press the button to lock the central control lock; press the button to unlock the central control lock.

State Save:

Before the power failure, the anti-theft alarm system was in a certain state. After the power failure, regardless of the length of time, the system will automatically return to the state before the power failure when it is recharged. (This function can effectively prevent criminals from using power outages to destroy the anti-theft system).

8. Roadside temporary parking light warning:

During vehicle travel, to ensure the safety of passengers getting on and off, when stopping temporarily to open the doors to allow passengers to get on or off while the engine is not off, the vehicle's turn signals will flash for 25 seconds to alert approaching vehicles, preventing any accidents.

Parking Assistance: (Applicable to four-button remote controls)

In large parking lots or at night to find a parking space, press the button once briefly, the horn will beep for 25 seconds, and the headlights will flash to indicate the vehicle's location. Press any key to stop.

Door not closed properly:

If the car door is not closed properly, the anti-theft system will sound the alarm after 20 seconds of setting the alert, and the headlights will flash simultaneously.

Emergency Disable Function

When the owner accidentally loses the remote control and cannot use the vehicle normally, please move the vehicle ignition key from OFF (LOCK) to ACC position, and twist it four times to deactivate the anti-theft function and use the vehicle normally. Remote learning function.

Remote Learning Function

  Step 1: Open the car door within 5 seconds and turn the vehicle ignition key from OFF (LOCK) to ACC position, twist it three times, and stop at the ACC position. At this time, the vehicle lights blink once and the horn sounds once, indicating that the vehicle has entered the learning state. Press any button on the remote control lightly, and the vehicle lights blink twice and the horn sounds twice, indicating that the remote control learning is successful, and the system can continue to learn the next remote control. (The system can store a maximum of 4 remote control codes)
