private model konnwei kw903 elmwifi ios apple and android gm fault diagnosis equipment

SSID: CLKDevices

Port: 35000

Range: 50 ft (Line of sight)

Antenna: Internal

Power Consumption: 0.75 Watts (With Power Switch)

Wifi Standard: 802.11a/b/g

Operating Temperature: -15 to 100 Degrees Celsius

Plastic: Automotive Grade
Physical Dimensions: 2.75 x 1.25 x 1.2 inches

Description

CLKis capable of communicating with vehicles which adopt following protocols:

ISO 9141

ISO 11898 (aka. CAN)

ISO 14230 (aka. KWP2000)

ISO 15765 (aka. CAN)

SAE J1939

CLKis able to detect and interpret these protocols automatically. It also provides support for high speed communications and a low power sleep mode. It uses AT commands to communicate with a host device (PC, notebook, iPhone, iPod touch, iPad and so on). There are plenty of software packages available, which are fully compatible withCLK. Some of them have pretty useful features, such as engine running parameters monitoring, DTC reading and clearing, MPG meter, etc. You can even write your own software on a specified hardware platform if you wish, because the AT commands are fully documented and very well explained.CLKIt measures only 2.7 x 1.25 x 0.9 inches, and it comes with a 6 ft OBDII cable for easy installation. It also includes a built-in power switch to prevent the need for constantly disconnecting your unit from the OBDII port.It is compatible with 1996 and later vehicles.. Connecting to your iPhone / iPod touch is made by WIFI connection in adHoc mode.

If you have the appropriate software installed in the host device, you may be able to read the following parameters from your vehicle:

Vehicle Speed

"Revolutions Per Minute"，意思是每分钟转数

Fuel Consumption

Engine Coolant Temp

Fuel Pressure

Calculated Engine Load

Throttle Position

Intake Manifold Pressure

Air Intake Temperature

Timing Advance

Mass Air Flow

Fuel Level

Barometric Pressure

EVAP System Vapor Pressure

Fuel Trim
