Heavy Truck Howo Dump Truck China Heavy Truck Howo Truck Front Four Rear Eight Dump Truck

Truck Model

 ZZ3317N3567W,8x4

Truck Brand

SINOTRUK –HOWO

Driving Type

Left Hand Driving

Dimension(Lx W xH)（unloaded）（mm）

10350x2550x3450

Cargo body size (L*W*H)

7300x2300x1500mm

Cargo body thickness(mm)

bottom:8mm, side:6mm，底8边6

Lift type of Carriage

Front tlifting，前顶举升

Fuel tanker capacity(L)

300L with locking fuel cap

Clutch

Single-plate dry clutch Φ430mm

Engine Model

(Steyr technology, made in China)

Model

WD615.47，4- stroke direct injection diesel engine, 6 cylinders in line with water cooling , turbo-charging and inter-cooling

Horse Power, max（kw/rpm）

371hp

Emission

EURO 2

Maximum torque

1500Nm @ 1100-1600rpm

Displacement:

9.726L

Fuel Type

diesel

Transmission

Model

HW19710,10 forwards and 2 reverse

Brake system

Service brake

Dual circuit compressed air brake

Parking brake

spring energy, compressed air operating on rear wheels

Auxiliary brake

Engine exhaust brake

Steering system

Model

Germany type, hydraulic steering with power assistance

Front axle

HF9 , Steering with double T-cross section beam

Loading capacity:9000KG

Rear axle

HC16, Pressed axle housing, central double reduction with differential locks between axles and wheels

Loading capacity: 16000kg

Chassis

Frame: U-profile parallel ladder frame with section of 300*80*8mm and reinforced subframe all cold riveted cross member

Front suspension: semi-elliptic leaf springs, hydraulic telescopic double-action shock absorbers and stabilizer

Rear suspension: semi –elliptic leaf spring and bogie springs

Color

Optional

Tire

12.00R20 radial tire, 12+1 spare

Electrical system

Operating voltage

24V,negative grounded

Starter

24V,7.35KW

Alternator

28V,1500W

Batteries

2*12V.165Ah

Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light.

Cab

HW76 cab, (single sleeping, with air-condition), all-steel forward control,70ºhydraulically tiltable to the front, 2- arm windscreen wiper system with 3 speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers
