kx306 slide projector
KX306 幻灯机 |
CN¥ 0.0 |
Product Name: Slide Projector
Item No.:DX 1 16
Package: Packaging bag
Product dimensions: 14*7*14 CM
Weight per unit: 0.1 KG
Number of boxes to be packed: 600 PCS
Box dimensions: 60*50*55 CM
Self-made slide projector course materials
A slide projector is an optical device that can magnify images and project them onto a screen. It is an important educational equipment widely used in electrical education. A slide projector mainly consists of a light source, a condenser lens, and a projection lens. When projecting transparent images, the light from the light source is focused by the condenser lens, providing uniform illumination on the image. The projection lens then creates an enlarged inverted real image on the screen. The magnification ratio of the slide projector is equal to the ratio of the distance from the lens to the screen to the focal length of the lens. For projecting opaque images or flat objects, a reflective slide device can be used. Light from a strong source is focused by a concave mirror and directed at the image placed on a reflection table, after which the reflected light passes through a plane mirror and an objective lens to produce an enlarged image, which is then displayed on the screen.
Experimental Objectives: 1. Understand the structure and principles of telescopes and microscopes
2. Understand the importance of the applications of convex lens imaging in human life and social development, and grasp the continuous advancement of technology.
Experimental Cognition<t_XXXXXXXXX> <t_XXXXXXXXX>
Focusing TubeTool used to block peripheral light
Convex and Concave LensesConcave mirrors and convex mirrors form images according to the laws of light reflection: the angle of incidence equals the angle of reflection, and light that enters along the normal at the reflection point reflects with the same path but in the opposite direction.
Experimental Steps<t_XXXXXXXXX> <t_XXXXXXXXX>
1. Experimental preparation: Identify experimental equipment: focusing tubes, concave and convex lenses.
Experimental Report<t_XXXXXXXXX> <t_XXXXXXXXX>
In this hybrid optical system, the deep ellipsoidal reflector enhances the utilization rate of the light source. The focusing mirror component is commonly used in basic projectors, while the combined focusing and reflecting optical component is typically found in more advanced projectors. When operating, the light emitted by the light source is reflected by the reflector onto the focusing mirror. After focusing, most of the light is evenly and concentratedly directed onto the slide. The light passes through the projection lens, resulting in an enlarged inverted real image on the screen. Since the imaging produced by a convex lens is inverted, the slide must be placed upside down in the optical path of the projector during projection.
