Human Body Induction Switch Infrared Small Curtain Mobile Detector Sensor Wired Infrared Alarm

  Small and elegant shape design, wall hanging or ceiling installation suitable for any position installation, vertical or horizontal induction, high sensitivity, flame retardant shell, low noise high sensitivity binary rectangular infrared; Warning distance: 6m * 3m curtain type current consumption: 12.5mA voltage: 10-16VDC ambient temperature:-10-+ 50℃, alarm Display: Red LED on, protection range: 6m (horizontal);3.6m (vertical)

Parameters:

Operating temperature: 9-15V alarm current: 10mA quiescent current: 30uA

Detection angle: 120 degrees detection distance: 8*8m working temperature:-10 ℃ ~ 50 ℃

Scope of Application: living room, financial Room, warehouse, room, window side, office, hotel, shop

1. Suitable for door, window and balcony protection, wall hanging or ceiling installation
2. Small and elegant shape design, suitable for installation in any position
3. Vertical or horizontal induction
4. High sensitivity
5. Flame retardant shell
Technical parameters:
1. Sensor: low noise and high sensitivity binary rectangular infrared
2. Detection speed: 0.2-7 meters per second
3. Operating Temperature:-10-+50 ℃
4. Power input: 10-16VDC,12.5mA
5. Lens: Fresnel vertical protective lens
6. Protection range: 6m (horizontal);3.6m (vertical)
7. Installation height: up to 3.6m
8. Installation position: wall hanging or ceiling
9. Anti-RF interference:>20V/m-1000MHz
10. Alarm Display: Red LED on
11. Alarm Time: 3 seconds
12. Alarm output: normally closed, 24VDC 0.1A
13. Tamper-proof switch: normally closed, comforter remove open circuit, 24VDC 0.1A
14. Working humidity: 95%
15. Weight: 30g
16. Size: 70 × 28 × 25mm
Specifications:
Warning distance: 6m * 3m curtain type current consumption: 12.5mA voltage: 10-16VDC ambient temperature:-10-+ 50℃
Alarm output: normally closed, 24VDC 0.1A sensing speed: 0.2-7 meters per second
