| ps-0.06 48cm * 100y | CN¥ 150.0 |
Pujiang Bochang New Material Technology Co., Ltd 15yr.
Contacts Kuangqunhua Chat
Mobile 15657905600
13575935581
Attention! Attention! Attention! The price of 3.3 yuan per square meter is for a thickness of 0.06 mm; prices vary for other thicknesses.
Readiness Guide for Customer Purchases
Note 1——Product Name and Ingredients
PS Hot Melt Adhesive Film:Polyester
Note 2——Details Parameters/Features/Device usage recommendations
Appearance: milky white Underlay material: single silicone oil release paper Melting point: 120~130℃
Steaming and pressing temperature: 130~160℃ Steaming and pressing time: 10~15S
Pressure: 1~3 Kg/cm2Product specifications: thickness 0.05~0.2mm, width 48~140cm
Thickness tolerance: ±0.005mm Adhesion strength: >35N/2.5cm
Features: fabric compounding/water resistance, dry cleaning clothing lining/waterproof zippers/leather chains/industrial shoe materials/embroidery patterns, PVC labels, woven labels, and other label bonding.
Note 3——Size specifications / Minimum order quantity
(<t_product_existing_thickness> is as follows)Large quantity in stock:0.06mm, 0.08mm, 0.10mm, 0.12mm, 0.15mm, 0.18mm, 0.20mmOther thicknesses need to be custom-made.)
The standard specifications are 48cm * 100y, with each roll measuring 43 square meters. Please place orders by specifying the total number of rolls (for example: 43 square meters, 86 square meters, 129 square meters, and so on).
Note 4 – Transportation
Heavy items are usually shipped via logistics services
1. All products at this store are not covered by shipping!
2. For default shipping, please enter “0” for the shipping cost when placing the order. This indicates free shipping, and you will need to collect the goods at the delivery station.
3. Our store offers free sample delivery; please contact customer service for samples.
Note 5--Application Scope
Fabric compounding/water resistance, dry cleaning clothing lining/waterproof zippers/leather chains/industrial shoe materials/embroidery patterns, PVC labels, woven labels, and other label bonding: The pressing temperature and time are only recommended process parameters and depend on the pressing equipment, thickness of the material being bonded, thermal conductivity, and pressure. Users must confirm through actual testing based on specific conditions.
