CIRCUIT BREAKER 6KA 2POLE C10





• Product information details

• Technical data

• CAx data

Technical data

		Miniature circuit breaker 400V 6kA,2 pole, C, 10.0
Version
Product brand name		SENTRON
Product Name		Circuit breaker
General Technical data
Pole number		2
Number of Poles/remarks		2p
Release feature level		C
Circuit breaker/foundation type		5SY6CC
Mechanical service life (conversion cycle)/typical		20,000
Overvoltage category		3
Voltage
Voltage type		AC
Insulation voltage
● multi-phase operation time/AC time/measured value		440V
Power supply voltage
Power supply voltage/AC time/measured value		400V
Power supply voltage frequency
● measured value		50/60Hz
Protection level
Protection class IP		IP20 with connecting wire
Energy limit level		3
Switching Capacity
Current on-off capability
● according to EN 60898/measured value		6 kA
Dissipation
Loss Power [W] /current measurement value/AC/in hot running state/each electrode		1.5W
Electricity
Rated current In / IEC,DIN / VDE/at 40 Cel		9.6 A
Current/AC time/measured value		10 A
Suitability of use		Machinery manufacturing/industry
Product Details
Product equipment/contact protection		Yes
Product components
● upper combination terminal		Yes
● lower combination terminal		Yes
Product Features
● comply with the main switch features of EN 60204-1		No
● halogen-free		Yes
● sealable		Yes
● Silicon-free		Yes
Product Expansion/installation/auxiliary device		Yes
Product Features
Product function/neutral line that can be cut off together		No
Short Circuit
Short circuit current (Icn) breaking capacity
● AC/according to UL 1077 and CSA C22.2 No. 235		5 kA
● DC hours/according to EN 60898-2		10 kA
Number
Number of test cycles/suitable for environmental testing/according to IEC 60068-2-30		28
