Main parameters and specifications of doorbell

 1. Master control: XR8722. Memory: 32MB flash

 3. Sensor: 30W GC0328 CMOS sensor4. Lens: 100 ° wide angle lens

  sensor Performance: supports automatic white balance, automatic gain control, and automatic backlight compensation.

 5. Signal-to-noise ratio: ≥ 41dB

 6. Minimum illumination: 0.8Lux/F1.4 (color mode),0.3Lux/F1.4 (black and white mode)

 7. Night vision: 2 LEDs high-power infrared lights night vision distance: 1 m the best effect, the longest distance is 3 m

 8. Video format: JPG9. Video size/frame rate: 480p/7fps

 10. Video Recording Method: 1. Button triggers video recording;11. Cloud storage map: 5 seconds (5 images)

 12. Battery type/capacity: Polymer 803035/800mAh battery Discharge Time: Polymer battery sleep standby for 1 year

 13. Network protocol: TCP/IP/HTTP/TCP/UDP/DHCP/DNS/DDNS/NTP/RTP/P2P

  WIFI connection: 2.4GHz wifi, supported (802.11 B/g/n)

 14. Ding dong: support RF 433MHZ ding dong

 15. Storage: Supports Cloud Storage (without TF card function),3 days free circulation cloud storage"

 16. Working voltage: Polymer 803035/3.7V

 17. Work Current: work current 219mA, deep sleep current 10mA, open infrared work current 280mA

 18.USB charging voltage: DC 5V / 1.5A19. Storage temperature (℃) :(0℃ ~ 50℃)

 20. Operating temperature (℃) :-10 ~ 50℃, working humidity <95%

wake-up mode: 1. Doorbell button wake-up,

APP access doorbell rules: 1 main account +8 Sharing accounts = 9 users can connect to the doorbell, only 3 users can preview the screen at the same time, only one user can talk to the doorbell at a time"

purpose: Guests can make video and voice calls and make short-term video recordings when visiting. The host can know the information of the visitor without opening the door.

Features: wireless connection, ultra-low power consumption, can support multiple accounts to watch online at the same time

  packing specification: Color box size97*82 * 35mm

weight: 120g

carton size: 430*370 * 214mm

packing: 100

weight: 12.6KG
