High-performance fiber double-sided tape has the following characteristics: The middle of the adhesive layer contains a thin layer of high-temperature-resistant glass fiber mesh (the glass fiber maintains size stability and virtually no deformation over a very wide temperature range), which provides stable dimensions in both the horizontal and vertical directions without deforming.

-         The range of materials that can be pasted is very wide, including rubber.PP/PE,PBT/PET,ABS,PMMAPlastic, metal, inorganic glass, and other materials.

-         Can maintain the adhesive bond without slipping over a wide temperature range (the temperature range depends on the properties of the adhesive material and the weight it supports).

-         In winter0Perform the adhesive operation in different environments such as above 15℃ in spring and summer, etc. (Note: The operating environment temperature should be 15-35℃, and as the temperature continuously decreases, the adhesive layer will gradually harden, making it more difficult to adhere.) Once the adhesive is applied, it can maintain good adhesion effects in a wider temperature range.

Product number adhesive⁽¹⁾Thickness and Backing Tape⁽²⁾Thickness Double-sided release paper thickness Total thickness

(1).The adhesive is on the outside of the tape roll, and it is exposed when the roll is unrolled.2The adhesive is located on the inside of the tape roll, and it is exposed when the release paper is peeled off.

Product code Initial adhesive force (D3121) 180° Peel force (D3330) 90° Peel force

GF0302 16#(Roller ball number) 65N/25mm 19.7N/25mm

Note: Due to differences in experimental conditions, the above data are typical values for reference only and cannot be used as product standards.

Tape Use Tips:

-The adhesive strength depends on the contact area between the adhesive surface and the surface to be adhered, so appropriate pressure and time can improve the bonding strength.

-The surface of the material to be pasted should be clean and free from oil and grease. If necessary, it can be cleaned with solvents such as isopropanol and acetone.

-The adhesive operation environment temperature is room temperature. At lower temperatures, the adhesive film becomes harder, making it more difficult to paste.

Suggested Application:

Suggested for

(1At the same time, it is necessary to paste two types of difficult-to-paste materials.

(2）需耐较为宽广的温度范围的场合，如：

-The adhesive of furniture and building sealant strips

           -Composites of difficult-to-adhere materials

Storage:

-First in, first out.

-Store in a dry and cool place and avoid direct sunlight.

-The storage period is two years from the date of production, provided that the storage conditions are appropriate.
