Product Overview

Mitsubishi FX5U PLC CPU FX5U-64MR/ES CPU Module Controller PLC

FX5U;CPU;AC;32 Inputs;32 Relay Outputs;3xAnalog;Eth;RS-485

FEATURES AT A GLANCE

Mitsubishi PLC CPU

The Mitsubishi FX5U series iQ platform compatible programmable logic controller (PLC) has 16 digital input (type 24VDC
sink/source) and 16 relay/transistor outputs. MELSEC communication protocol (3C/4C Frames) and MELSOFT connection. It has 64k
steps program capacity and 16 built-in inputs. The FX5U continues the FX tradition of total flexibility by offering a huge range
of new and existing add-on options. It further enhances the built-in functions of Ethernet, analogue I/O, data logging, position
control, security, communication and networking functions incorporated as a standard. It will provide users with the ability to
specify more powerful systems, but with fewer overall components, saving time and cost.

Features and Benefits

Voltage rating ranges between 100VAC and 240VAC
Expanded input/output area for networks and complex applications
Can be upgraded by combining with expansion modules
Built-in SD card slot
Voltage rating ranges between 100VAC and 240VAC
Run/Stop/Reset switch
Built-in Ethernet port, RS485
Displays the input and output states via LEDs
Integrated real-time clock
Programming software is GX Works3
Operating temperature ranges between 0°C and 55°C

Right elevation

Left elevation

Front elevation

PRODUCT SPECIFICATIONS

No	Item	Data
1	Type	FX5U
2	Power Supply (V)	100-240
3	Current Type	AC
4	Program Memory	64K STEPS
5	Program Memory Unit	FLASH
6	Integrated Digital Inputs	16
7	Integrated Digital Outputs	16
8	Integrated Analogue Inputs	2
9	Output Type	RELAY
10	Local I/O Points	256
11	Local + Remote I/O Points	512
12	Expandable	YES
13	Cycle Time LD (ns)	34
14	Cycle Time MOV (ns)	34
15	Ethernet Port	1
16	RS-485	1
17	Power Consumption (W)	30
18	Buffer Battery	OPTION
19	Protection Class	IP10
20	Min. Ambient Temperature (°C)	0
21	Max. Ambient Temperature (°C)	55
22	Series	MELSEC IQ-F SERIES
